Daikin RKS50F2V1B [10/31] Electrical data
![Daikin RKS50F2V1B [10/31] Electrical data](/views2/1776840/page10/bga.png)
3
1
4
• Split Sky Air • Outdoor Units
10
• Outdoor Units • R-410A • RKS-F2V1B
4 Electrical data
Representative unit combination Power supply Comp. OFM IFM
Indoor unit Outdoor unit Hz-volts Voltage range MCA MFA RHz RLA W FLA W FLA
FTKS50FV1B RKS50F2V1B
50 - 220
Max. 50Hz 264V
Min. 50Hz 198V
19.75 20.0 67
6.7
53 0.27 43 0.1650 - 230 6.4
50 - 240 6.1
FTKS60FV1B RKS60F2V1B
50 - 220
Max. 50Hz 264V
Min. 50Hz 198V
19.75 20.0 84
8.7
53 0.32 43 0.1650 - 230 8.3
50 - 240 7.9
FTKS71FV1B RKS71FV1B
50 - 220
Max. 50Hz 264V
Min. 50Hz 198V
19.75 20.0 57
10.3
66 0.40 43 0.1950 - 230 9.9
50 - 240 9.4
3D056032A
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency (Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Rated motor output (W)
NOTES
1. RLA is based on the following conditions:
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
http://extranet.daikineurope.com, select ’’E-Data Books’’. Finally, click on
the document title of your choice.
