• Outdoor Units • R-410A • RKS-F2V1B
1
5
• Split Sky Air • Outdoor Units
13
5 Capacity tables
5 - 1 Cooling capacity tables
FVXS50FV1B+RKS50F2V1B
Cooling 220-240V [50Hz]
AFR 10.7
BF 0.13
Indoor
Outdoor temperature (°CDB)
EWB EDB 20 25 30 32 35 40
(°C) (°C) TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
3D056338
SYMBOLS
AFR: Air flow rate (m
3
/min)
BF: Bypass factor
EWB: Entering wet bulb temp. (°C)
EDB: Entering dry bulb temp. (°C)
TC: Total capacity (kW)
SHC: Sensible heating capacity (kW)
PI: Power input (kW)
NOTES
1. Capacities are based on the following conditions:
(1) Corresponding refrigerant piping length: 7.5 m
(2) Level difference: 0 m
2. shows nominal (rated) capacities and power input.
