ED04-805 Features
Room Air Conditioners E-Series 5
05RAG19A- 18
Notes
- When this function is ON, the maximum capacity is
also down. (Approx. 20%)
- In case of the multi system connection, the unit drops
maximum capacity to equal level with nominal
capacity in stead of current control.
- This function can only be set when the unit is running.
Pressing the operation stop button causes the
settings to be canceled.
- This function and "Powerful operation" cannot be
used at the same time. (Priority is given to Powerful
operation.)
ECONO Mode
05RAG19A- 19
= Sensing human presence utilizing infrared rays =
Max.
7m
110˚
90˚
Coverage Area
within 7 m (Max)
INTELLIGENT EYE
INTELLIGENT
EYE Sensor
05RAG19A- 20
= Just one push of the [SENSOR] button =
Sensor
INTELLIGENT EYE
TIMER
ON
CANCEL
OFF
