Specifications Si04-115
6 Specification
220V, 60Hz
Notes:
"
MAX. interunit piping length: 25m
"
MAX. interunit height difference: 15m
"
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
"
The data are based on the conditions shows in the table below.
"
The data on the conditions (CNS3615):
(Conditions)
Models
Indoor Units FTK25JVET9 FTK35JVET9
Outdoor Units RK25JVET9 RK35JVET9
Capacity (Min.~Max.)
kW 1.3~3.2 1.4~4.0
kcal/h 1,100~2,750 1,200~3,450
Moisture Removal L/h 1.2 1.9
Running Current (Min.~Max.) A 3.1~7.1 3.4~8.9
Power Consumption (Min.~Max.) W 470~1,300 520~1,650
Power Factor (Min.~Max.) % 68.9~83.2 69.5~84.3
COP (Min.~Max.) W/W 2.77~2.46 2.69~2.42
EER (Min.~Max.) kcal/h·W 2.34~2.11 2.31~2.09
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTK25JVET9 FTK35JVET9
Front Panel Color Almond White Almond White
Air Flow Rate
m³/min
(cfm)
H7.5 7.8
M6.4 6.7
L5.4 5.5
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal / Washable / Mildew Proof Removal / Washable / Mildew Proof
Running Current (Rated) A 0.21 0.21
Power Consumption (Rated) W 45 45
Power Factor % 97.4 97.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 37 / 34 / 30 38 / 35 / 32
Outdoor Units RK25JVET9 RK35JVET9
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model RC1X26BTNT RC1X26BTNT
Motor Output W 750 750
Refrigerant
Oil
Model SUNISO 4GSD.I. SUNISO 4GSD.I.
Charge L 0.4 0.4
Refrigerant
Model R22 R22
Charge kg 0.72 0.92
Air Flow Rate m³/min 29.0 27.5
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Min.~Max.) A 2.89~6.89 3.19~8.69
Power Consumption (Min.~Max.) W 425~1,255 475~1,605
Power Factor (Min.~Max.) % 66.8~82.8 67.7~84.0
Starting Current A 4.3 5.5
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 31 32
Gross Weight kg 34 36
Operation Sound dBA 46 47
Drawing No. 3D029306 3D029307
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19.5°CWB
Outdoor ; 35°CDB/24°CWB
5m
Models FTK25JVET9 FTK35JVET9
(Rated) Cooling
Capacity kW (kcal/h) 2.0 (1,720) 2.7 (2,350)
Running Current A 3.9 5.0
Power Consumption W 755 1,035
COP (EER) W/W (kcal/h·W) 2.65 (2.27) 2.61 (2.27)
Standard Cooling Piping Length Power Source
CNS3615
Indoor ; 27°CDB/19.5°CWB
Outdoor ; 35°CDB/24°CWB
5m 60Hz 220V
