Printed Circuit Board Connector Wiring Diagram and Name Si04-115
12 Printed Circuit Board Connector Wiring Diagram
1. Printed Circuit Board Connector Wiring Diagram
and Name
1.1 FTK25/35J Series, FTX25/35J Series
Printed circuit board (1) (Control PCB)
Printed circuit board (2) (Signal Receiver PCB)
Printed circuit board (3) (Intelligent Eye Sensor PCB)
Name of
connector
Note: Other designations
1) S1 Connector for fan motor
2) S6 Connector for swing motor (Horizontal Flap)
3) S7 Connector for fan motor
4) S21 Connector for centralized control to 5 rooms
5) S27, S36 Connector for control PCB
6) S26 Connector for signal receiver PCB
7) S32 Connector for room temp/Heat exchanger thermistor
8) S35 Connector for Intelligent Eye Sensor PCB
1) V1 Varistor
2) JA ADDRESS SETTING JUMPER
JB Fan speed setting when compressor is OFF on thermostat.
JC Power failure recovery function.
∗
Refer to page 139 for more detail.
3) SW7 OPERATION SWITCH
4) LED1
(GRN)
LED for operation
5) LED2
(YLW)
LED for timer
6) LED3
(GRN)
LED for intelligent eye
