Specifications Si04-115
8 Specification
1.2 Heat Pump
220-230-240V, 50Hz / 220-230V, 60Hz
Notes:
"
MAX. interunit piping length: 15m
"
MAX. interunit height difference: 15m
"
Amount of additional charge of refrigerant 20g/m for piping length exceeding 10m
"
The data are based on the conditions shows in the table below.
Models
Indoor Units FTX25JVEA9 FTX35JVEA9
Outdoor Units
RX25JVEA9 RX35JVEA9
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.54 (1.3~3.0) 3.4 (1.3~4.0) 3.60 (1.4~3.8) 4.2 (1.4~5.1)
Btu/h 8,700 (4,400~10,300) 11,600 (4,400~13,600) 12,300 (4,800~13,000) 14,300 (4,800~17,600)
kcal/h 2,190 (1,100~2,600) 2,920 (1,100~3,440) 3,100 (1,200~3,300) 3,600 (1,200~4,400)
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 5.1 5.6 7.4 7.3
Power Consumption Rated
(Min.~Max.)
W 900 (430~1,250) 1,100 (350~1,350) 1,360 (500~1,720) 1,340 (405~1,900)
Power Factor % 80.2-76.7-73.5 / 80.2-76.7 89.3-85.4-81.8 / 89.3-85.4 83.5-79.9-76.6 / 83.5-79.9 83.4-79.8-76.5 / 83.4-79.8
COP W/W 2.82 3.09 2.65 3.13
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTX25JVEA9 FTX35JVEA9
Front Panel Color Almond White Almond White
Air Flow Rate
m³/min
(cfm)
H 7.5 (265) 8.8 (311) 7.8 (275) 8.7 (307)
M 6.4 (226) 7.5 (265) 6.7 (237) 7.4 (261)
L 5.4 (191) 6.2 (219) 5.5 (194) 6.2 (219)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps and Auto 5 Steps and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removal / Washable / Mildew Proof Removal / Washable / Mildew Proof
Running Current (Rated) A 0.17-0.18-0.18 / 0.21-0.21 0.17-0.18-0.18 / 0.21-0.21 0.17-0.18-0.18 / 0.21-0.21 0.17-0.18-0.18 / 0.21-0.21
Power Consumption (Rated) W 37-40-43 / 45-48 37-40-43 / 45-48 37-40-43 / 45-48 37-40-43 / 45-48
Power Factor % 98.9-96.6-99.5 / 97.4-99.4 98.9-96.6-99.5 / 97.4-99.4 98.9-96.6-99.5 / 97.4-99.4 98.9-96.6-99.5 / 97.4-99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×185 273×784×185
Packaged Dimensions (W×D×H) mm 834×325×218 834×325×218
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 37 / 34 / 30 37 / 33 / 30 38 / 35 / 32 38 / 35 / 31
Outdoor Units RX25JVEA9 RX35JVEA9
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model RC1X26BTNT RC1X26BTNT
Motor Output W 750 750
Refrigerant
Oil
Model SUNISO 4GSD.I. SUNISO 4GSD.I.
Charge L 0.4 0.4
Refrigerant
Model R22 R22
Charge kg 0.72 0.95
Air Flow Rate
m³/min 28.0-29.0-30.0 / 29.0-30.0 25.0-25.5-26.5 / 25.5-26.5 26.5-27.5-28.0 / 27.5-28.0 22.5-23.5-24.0 / 23.0-24.0
cfm
988-1,024-1,059
/ 1,024-1,059
883-900-935 / 900-935 935-971-988 / 971-988 794-830-847 / 812-847
Fan
Type Propeller Propeller
Motor Output W 25 25
Running Current (Rated) A 4.93-4.92-4.92 / 4.89-4.89 5.43-5.42-5.42 / 5.39-5.39 7.23-7.22-7.22 / 7.19-7.19 7.13-7.12-7.12 / 7.09-7.09
Power Consumption (Rated) W 863-860-857 / 855-852
1,063-1,060-1,057
/ 1,055-1,052
1,323-1,320-1,317
/ 1,315-1,312
1,303-1,300-1,297
/ 1,295-1,292
Power Factor % 79.6-76.0-72.6 / 79.5-75.8 89.0-85.0-81.3 / 89.0-84.9 83.2-79.5-76.0 / 83.1-79.3 83.1-79.4-75.9 / 83.0-79.2
Starting Current A 5.6 7.4
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (W×D×H) mm 797×310×599 797×310×599
Weight kg 31 32
Gross Weight kg 34 36
Operation Sound dBA 45-46-47 / 46-47 46-47-48 / 47-48 46-47-48 / 47-48 47-48-49 / 48-49
Drawing No. 3D029308 3D029309
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Standard Cooling Heating Piping Length
JIS C 9612
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
