SPECIFICATIONS
EUWA*40MX EUWA*50MX EUWA*60MX EUWA*80MX EUWA*100MX
111 140 166 211 276
39.1 53.7 64.0 79 110
100-75-55-0 100-88-76-63-50-38-25-0
semi-hermetic single screw compressor
R-134a
1/1 1/1 1/1 2/2 2/2
2,221x3,973x1,109 2,248x3,973x2,216
1,391 1,600 1,705 2,710 3,210
1,439 1,655 1,798 2,790 3,345
91 97 95 94 100
3~, 50Hz, 400V
3~, 50Hz, 230V 3~, 50Hz, 230V 3~, 50Hz, 230V 3~, 50Hz, 230V 3~, 50Hz, 230V
Nominal cooling capacity kW
Nominal power input kW
Capacity steps %
Compressor type
Refrigerant type
No. of circuits/compressors
Dimensions HxWxD mm
Machine weight kg
Operation weight kg
Sound power level dBA
Power supply Y1
T1
option option description model-type unit size
availability
number PED d s 40 50 60 80 100 120 160 180 200
Completely combinable options
op01 liquid line solenoid valve std std std
op03 dual pressure relief valve on the condenser o std std o o o o o o o o o fact. mounted
op12 suction stop valve o std std o o o o o o o o o fact. mounted
op52 main isolator switch o o o o o o o o o o o o fact. mounted
op57 a-meter, V-meter o o o o o o o o o o o o fact. mounted
OPLN low noise operation o o o o o o o o o o o o fact. mounted
OPCG condenser protection grilles o o o o o o o o o o o o fact. mounted
o available
std standard
OPTIONS
EUWA*120MX EUWA*160MX EUWA*180MX EUWA*200MX
316 400 438 475
130 164 178 191
100-88-76-63-50-38-25-0 100-87-74-61-48-42-36-18-0 100-88-74-62-48-43-36-20-0 100-87-74-61-48-42-36-18-0
semi-hermetic single screw compressor
R-134a
2/2 2/2 2/2 2/2
2,248x3,973x2,216 2,250x5,906x2,238
3,260 5,400 5,450 5,500
3,385 5,488 5,544 5,603
98 99 100 100
3~, 50Hz, 400V
3~, 50Hz, 230V - - -
Nominal cooling capacity kW
Nominal power input kW
Capacity steps %
Compressor type
Refrigerant type
No. of circuits/compressors
Dimensions HxWxD mm
Machine weight kg
Operation weight kg
Sound power level dBA
Power supply Y1
T1
