18 FWV/FWH1-10C(F)6V1
BACKGROUND
A completely new range of fan coils will be available by spring next year. Main features of these
units will be their low sound level, their new modern design and controls.
Moreover, each model will be available in 7 capacity versions, both 2- and 4-pipe.
FWV1C(F)6V1 FWH1C(F)6V1 FWM1A(F)6V1
FWV2C(F)6V1 FWH2C(F)6V1 FWM2A(F)6V1
FWV3C(F)6V1 FWH3C(F)6V1 FWM3A(F)6V1
FWV4C(F)6V1 FWH4C(F)6V1 FWM4A(F)6V1
FWV6C(F)6V1 FWH6C(F)6V1 FWM6A(F)6V1
FWV8C(F)6V1 FWH8C(F)6V1 FWM8A(F)6V1
FWV10C(F)6V1 FWH10C(F)6V1 FWM10A(F)6V1
MODEL RANGE
FEATURES
• Low wall unit FWV :
• new casing
• vertical air outlet
• adjustable air outlet grille
• with side doors
• new electronic or mechanical controller
• Flexi type unit FWH :
• new modern casing
• adjustable air outlet grille
• can be installed on either floor or ceiling
• Concealed flexi type unit FWM :
• FWHM and FWVM are integrated into 1 model
• standard drainpan for both vertical and horizontal use
FWM3A(F)6V1
Low wall unit / flexi type unit
FWM1-10A(F)6V1
Concealed flexi type unit
FWH3C(F)6V1FWV3C(F)6V1
