![Daikin FTD20JEVLK [21/24] Specifications](/img/pdf.png)
Daikin FTD20JEVLK [21/24] Specifications
![Daikin FTD25JEVLK [21/24] English](/views2/1785242/page21/bg15.png)
English
1-19
NOTE:
This product is not designed for repacking. In case of re-packing, contact to Daikin Dealer.
MODEL INDOOR UNIT FTD20JEVLK FTD25JEVLK
OUTDOOR UNIT RD20JEVLK RD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
O
C/19WB
O
C
OUTDOOR
35DB
O
C/24WB
O
C
RATED CURRENT A 8.80 11.1
RATED POWER INPUT kW 1.92 2.44
CAPACITY Btu/h 19000 22700
kW 5.57 6.65
EER
(Btu/h)/W 9.89 9.30
COOLING (T3)
INDOOR
29DB
O
C/19WB
O
C
OUTDOOR
46DB
O
C/24WB
O
C
RATED CURRENT A 10.7 12.8
RATED POWER INPUT kW 2.33 2.80
CAPACITY Btu/h 16100 20000
kW 4.72 5.86
EER
(Btu/h)/W 6.90 7.14
NET WEIGHT INDOOR UNIT kg 14.0 14.0
OUTDOOR UNIT kg 49 57
REFRIGERANT R22 kg 1.60 1.80
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
MODEL INDOOR UNIT FTYD20JEVLK FTYD25JEVLK
OUTDOOR UNIT RYD20JEVLK RYD25JEVLK
RATED VOLTAGE V 220 220
RATED FREQUENCY Hz 60 60
COOLING (T1)
INDOOR
27DB
O
C/19WB
O
C
OUTDOOR
35DB
O
C/24WB
O
C
RATED CURRENT A 8.80 11.1
RATED POWER INPUT kW 1.92 2.44
CAPACITY Btu/h 19000 22700
kW 5.57 6.65
EER
(Btu/h)/W 9.89 9.30
COOLING (T3)
INDOOR
29DB
O
C/19WB
O
C
OUTDOOR
46DB
O
C/24WB
O
C
RATED CURRENT A 10.7 12.8
RATED POWER INPUT kW 2.33 2.80
CAPACITY Btu/h 16100 20000
kW 4.72 5.86
EER (Btu/h)/W
6.90 7.14
HEATING
INDOOR
20DB
O
C/--WB
O
C
OUTDOOR
7DB
O
C/6WB
O
C
RATED CURRENT A 8.70 10.6
RATED POWER INPUT kW 1.89 2.32
CAPACITY Btu/h 20000 24000
W 5860 7030
COP W/W
3.10 3.03
NET WEIGHT INDOOR UNIT kg 14.0 14.0
OUTDOOR UNIT kg 49 57
REFRIGERANT R22 kg 1.60 1.80
COUNTRY OF ORIGIN INDOOR UNIT
Malaysia
OUTDOOR UNIT
Malaysia
SPECIFICATIONS
1 IM-WMJ-0211(0)_DAIKIN (SASO)-E19 19 6/1/11 12:09:59 PM
