Daikin FTD20JEVLK [4/24] Outdoor unit
![Daikin FTYD25JEVLK [4/24] Outdoor unit](/views2/1785242/page4/bg4.png)
1-2
B
A
QR
ST
D
O
KLL
C
N
P
M
N
FE
C
G
H
IJ
All dimensions are in mm
Outdoor Unit
Dimension
Model
ABCDEFGH I JKLMNO
R(Y)D20JEVLK 855 628 328 508 181 44 93 149 101 113 603 126 164 17 49
R(Y)D25JEVLK 855 730 328 520 182 44 93 149 101 113 603 126 164 17 34
Dimension
Model
PQRST
R(Y)D20JEVLK 32 3 237375
R(Y)D25JEVLK 32 3 237375
1 IM-WMJ-0211(0)_DAIKIN (SASO)-E2 2 6/1/11 12:09:47 PM
