DAILY OPERATION COSTS
ELECTRICAL ENERGY:
NATURAL GAS:
Total natural gas consumption of warm air heaters
➧
141 m
3
TOTAL COST OF NATURAL GAS
➧
141 x 0,40 = 56,40 Euro
Unitary electrical capacity:
•
fan motor
➧
4,0 kW
•
burner
➧
0,6 kW
Total electrical consumption of warm air heaters
➧
20,8 kW/h
Destratifyer capacity
➧
0,13 kW
Total electrical consumption of destratifyer
➧
16,4 kW/h
TOTAL COST OF ELECTRICAL POWER
➧
(20,8+16,4) x 0,16 = 5,94 Euro
TOTAL DAILY OPERATION EXPENSES
➧
56,40 + 5,94 =
62,34 Euro
DAILY OPERTATION COSTS IN
RELATION TO VOLUMETRY:
62,34 Euro : 25.600 m
3
= 0,0024 Euro/m
3
DAILY OPERATION COSTS
IN RELATION TO SURFACE:
62,34 Euro : 3.800 m
2
= 0,016 Euro/m
2
INSTALLED HEAT CAPACITY
IN RELATION TO VOLUMETRY:
(306 kW/h x n°2) : 25.600 m
3
= 23,9 W/m
3
INSTALLED HEAT CAPACITY
IN RELATION TO SURFACES:
(306 kW/h x n°2) : 3.800 m
2
= 161,1 W/m
2
(The data mentioned above represents European average values)
