CONCLUSIONS
ΔT air supply < 30°C Very low air stratification ≤ 0,3°C/m
High thermal efficiency over 100%
if settled in condensation
Always restrained reduced consumption
Significant low thermal inertia Fast and simple tuning up, ideal for
discontinuous and irregular functioning
Running heaters only when the
working environment is employed
Substantial financial cutback
of operation
Total absence of intermediate
fluids such as water or steam
Absence of frost or inefficient
transformation stages
Option of installing a filter section
Option of taking exterior fresh air for
air volume exchange in the room
Summer only fan functioning option
An air treatment system,
that assures immediate comfort
Monoblock autonomous heaters
Systems that are easily improvable in
case of building surface extensions
Easy full recovery of heaters,
in case of displacement
Installation into or outside the rooms
to be heated
Central heating station is not required
meaning less overall costs
