24
SIZE AND LOCATION OF CONNECTIONS
Type 1-2 and 9-10
M
r
R
120
55
330
65
255
Type 3-4 and 11-12
40 345
130 55
625
M
r
R
M: delivery to system
R: return from system
r: water top-up
