Tecnoclima BESST/R 31 [39/40] Fault cause solution
![Tecnoclima BESST/R 11 [39/40] Fault cause solution](/views2/1788084/page39/bg27.png)
39
FAULT CAUSE SOLUTION
Noise and vibration
Contacts between metal bodies.
Check
Weak foundations.
Restore
Loosened screws
Tighten the screws
Low exhaust pressure
Low condensation air/water temperature.
Abnormal fan regulation operation.
Low refrigerant charge.
Check
Compressor drain valve leakage. Replace the component
High suction pressure
High inlet water temperature.
Thermostatic expansion valve faulty or open.
Check
Low suction pressure
Low inlet water temperature.
Thermostatic expansion valve faulty or obstructed.
Suction line throttled.
Filter clogged.
Evaporator exchanger obstructed.
Excessive quantity of antifreeze liquid in the hydraulic circuit
Check
