34
Switching off
Turn OFF the “SO” ON-OFF remote switch
The “OFF” indication starts flashing on the CONTROL
PANEL
Switching on the heating mode
Switching on
- Turn ON the “SEI” SUMMER-WINTER remote switch
- Turn ON the “SO” ON-OFF remote switch
The indicator LED
lights up on the control panel.
Switching off the heating mode
- Turn OFF the “SO” ON-OFF remote switch.
The “OFF” indication starts flashing on the CONTROL PANEL
In case of power failure for more than four hours, after
restoring the unit, keep it powered but switched off for at
least eight hours.
In case of power failure for less than four hours, after
restoring the unit, keep it powered but switched off for the
same number of hours the power failed.
It is recommended to switch the operating mode only once a
day
