![Daikin RKHWMX300C [42/64] X parameter settings](/views2/1788403/page42/bg2a.png)
42
FA ROTEX RoCon mb • 09/2017
6 x Parameter settings
Interlink fct Configuration for systems that are operated with 2 different target feed temperatures
(see chap.
3.6.6).
One possible application is e.g. the additional integration of an HP convector in a surface
heating and cooling system.
Prerequisite: 2 room thermostats are connected to ROTEX HPSU monobloc compact
plug connection J16.
– Off: Deactivated
– On: evaluation of the heating and cooling switching contacts at plug con-
nection J16 on the RoCon BM1 printed circuit board.
Activation of cooling mode only by switching the operating mode to "Cooling" (see
chap.
3.4.2).
Setting of the parameter [Room thermostat] is no longer evaluated.
a) Open switching contacts: only frost protection active
b) "Heating" and "Automatic 1" / "Automatic 2" operating mode active during the
switching cycles in day mode.
– Closed heating switching contact = IL1:
→ The system is regulated to the normal target feed temperature as per the
parameter settings in the "HC Configuration" > "Heating" level.
– Closed cooling switching contact = IL2:
→ The system is regulated to the increased target feed temperature (normal target
feed temperature + value of the parameter [T-Flow CH adj]. Priority if both
switching contacts are closed!
c) "Cooling" operating mode active.
– Closed heating switching contact = IL1:
→ The system is regulated to the normal target feed temperature as per the
parameter settings in the "HC Configuration" > "Cooling" level.
– Closed cooling switching contact = IL2:
→ The system is regulated to the reduced target feed temperature (normal target
feed temperature - value of the parameter [T-Flow Cooling adj]. Priority if both
switching contacts are closed!
N E Off
On
Off -
MF 1 Config Configuration of the multi-function output (230 V, J14 connection):
0: The output is without function.
1: Header pump – The output becomes active as soon as a system heating circuit reports
a heat requirement to the heat generator.
2: Circulation pump – The output is activated either after the time program of the circu-
lation pump or after the time program of the hot water generation, depending on the par-
ametrisation (see chap. 3.4.7).
3: Feeder pump – The output becomes active as soon as a heat requirement is pending
for the direct heating circuit of the heat generator.
N E 0 - 3 2 1
Air Purge Activation of automatic ventilation of the ROTEX HPSU monobloc compact and the con-
nected heating circuit (see chap. 3.6.10).
Off: Deactivated
On: Start of the Air Purge
N E Off
On
Off -
PWM Config
Emitter type System reaction time: depending on the water volume in the system and the heat ex-
changer type, heating or cooling a room may take more time. This setting can compen-
sate for a slow or fast heating/cooling system by adapting the device's output during the
heating/cooling cycle.
0: fast. Example: lower water volume and convectors.
1: slow. Example: higher water volume, floor heating circuits.
S E 0 -1 0 -
Pump dT heating Heating: required temperature difference between return and feed temperature. If a min-
imum temperature difference is required for good heat distribution system operation in
heating mode.
S E 3 - 10 5 1
Pump dT cooling Cooling: required temperature difference between return and feed temperature. If a min-
imum temperature difference is required for good heat distribution system operation in
cooling mode.
S E 3 - 10 5 1
Sensor Config
Tamb Config Configuration of the optional outside temperature sensor.
0: no sensor evaluation
1: sensor evaluation activated. To determine the target feed temperature, this sensor is
evaluated and shown on the standard display.
S E 0 - 1 0 -
Storage Config Configuration of the hot water generation:
Inactive: No function for hot water generation.
Sensor: Function for hot water generation is activated. A storage temperature sensor is
evaluated for hot water generation (if no storage temperature sensor is connected, an
error message is generated).
Thermostat: Function for hot water generation is activated. A thermostatic switch (On /
Off) is evaluated for hot water preparation, whereby "open terminals" is evaluated as "no
requirement".
N E Inactive
Sensor
Thermostat
Sensor -
Pressure Config Configuration of the sensor for detection of the water pressure of the system:
Off: No sensor evaluation
On: Sensor evaluation activated (if no pressure sensor is connected, an error message
is generated.)
N E Off
On
On -
Outside Temp Adap Individual adjustment for the measured value of the outside temperature relevant for the
control unit.
N E -5.0 to +5.0 kW 0.0 K 0.1 K
Sub-
level
Parameters Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
