![Daikin RKHWMX300C [52/64] Rotary switch setting configuration setup level](/img/pdf.png)
Daikin RKHWMX300C [52/64] Rotary switch setting configuration setup level
![Daikin RKHWMX300C [52/64] Rotary switch setting configuration setup level](/views2/1788403/page52/bg34.png)
52
FA ROTEX RoCon mb • 09/2017
6 x Parameter settings
6.13.1 Rotary switch setting: Configuration , "Setup" level
Sub-
level
Parameters Description Access Setting range
Min / Max
Factory
setting
Incre-
ment
BE HF
LCD Brightness Brightness of the display E E 0 - 100 % 50 % 10 %
LCD Illum Time Lighting duration of the display E E 5 - 120 s 30 s 1 s
Language National language of the display texts on the control unit E E German
English
French
Dutch
Italian
Spanish
Portuguese
German 1
Date Current date in day/month/year format. The current day of the week is calculated auto-
matically from the date.
E E
Time Time in hours/minutes format. E E
Keylock Function Release of the key lock function:
Off: Key lock cannot be activated.
On: Key lock can be activated with the rotary button (see chap. 3.1).
E E Off
On
Off -
Access Rights Access code entry. Setting digit-by-digit like a combination lock (see chap. 3.6.1). E E 0 - 9 0000 1
RoCon U1 assign Display only on connected room station:
Function of the RoCon U1 room station in the CAN data bus system:
Living Room: control panel for the heating circuit assigned in the parameter [HC Assign-
ment] (heating circuit ID).
Mixing Valve: Mixer circuit operating unit (as mixer circuit extension or as a free-standing
mixer circuit control unit)
In addition to the above functions, the room station can basically be used as a remote
control unit for the ROTEX HPSU monobloc compact and the entire RoCon system (with
activated terminal function) (see chapters
4.1 and 4.4.2).
N E Living Room,
Mixing Valve
Living Room -
PWM Config
Min Perform Pump Lower limit for modulation of the pump power N E 0 - 100 % 50% 1 %
Max Perform Pump Upper limit for modulation of the pump power N E 0 - 100 % 100% 1 %
Sensor Config
Tamb Config Configuration of the outside temperature sensor:
Off: takeover of the outside temperature from the heat generator to which the mixer mod-
ule is assigned by the heat generator ID (parameter [Boiler Assignment]), or no sensor
evaluation
On: sensor evaluation activated
N E Off
On
On -
Outside Temp Adap Individual adjustment for the measured value of the outside temperature relevant for the
control unit.
N E -5.0 to +5.0 kW 0.0 K 0.1 K
Terminaladress Setting of the terminal ID of the control panel for system access. The set value must be
unique throughout the entire system. Confirmation of this parameter with the rotary but
-
ton effects new initialisation of the control unit.
All settings except for "Off" authorise the user of the control unit to activate the terminal
function and thus to operate all RoCon system components with a valid device ID (see
chap.
3.4.9 and 4.1).
N E Off, 0 - 9 Off 1
Boiler Assignment Setting of the heat generator ID. Assignment of the RoCon M1 to the heat generator. Set-
ting must correspond to the value of the parameter [BUS ID HS] (see chap. 6.12,
tab. 6-14).
N E 0 - 7 0 1
HC Assignment Setting of the heating circuit ID of the mixer module.
Off: automatic assignment if there is only one mixer module in the system (system then
automatically takes over the address switch setting as the heating circuit ID irrespective
of the set value). The setting must always correspond to the heating circuit ID on the mix
-
er module address switch (see chap. 4.4.1, fig. 4-2).
0 - 9 = 0 - 9
10 = A
11 = B
12 = C
13 = D
14 = E
15 = F
N E Off, 0 - 15 Off 1
Tab. 6-15 Parameters in the "Configuration" rotary switch setting, "Setup" level
