8 Technical data
Installation and operating manual
26
EKHW(D/C/P)(300/500)(P)B
Daikin Altherma ST (Hot water storage tank)
008.1633099_00 – 06/2020
8.2.2 EKHWC
8‒2 Unpressurised (DrainBack) - DB
Model Identifier (x=A, B, C, …) EKHWCH300Bx EKHWC500Bx EKHWCH500Bx EKHWCB500Bx
Unit
Product data related to regulation (EU) 812/2013 and regulation (EU) 814/2013
Energy efficiency class — B
Standing loss S W 64 72
Hot water storage tank volume V litres 294 477
Specific standing loss (EN12977) (UA)
sb,s,a
W/K 1.43 1.59 1.59 1.59
Volume of the non-solar heat storage V
bu
litres 288 0 322 322
Basic data
Empty weight kg 49 65 70 76
Total filled weight kg 343 542 547 553
Dimensions (L×W×H) cm 59.5×61.5×164.6 79×79×165.8 79×79×165.8 79×79×165.8
Tilt dimension cm 175 184 184 184
Maximum permissible storage water
temperature
°C 85 85 85 85
Standby heat expenditure at Δ45K kWh/24h 1.5 1.7 1.5 1.7
Drinking water heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 18.6 24.5
Maximum operating pressure bar 10
Domestic water heat exchanger surface m
2
3.8 4.9
1ststorage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 9.7 — 10
Heat exchanger surface area m
2
1.9 — 1.95
2ndstorage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres — — — 10.9
Heat exchanger surface area m
2
— — — 2.2
Pressurised solar heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres — — — —
Heat exchanger surface area m
2
— — — —
Solar heating backup (stainless steel 1.4404)
Water capacity heat exchanger litres — 3.8
Heat exchanger surface area m
2
— 0.74
Thermal output data
Efficiency characteristic N
L
acc. to DIN4708
(1)
— 2.2 — 2.3 2.3 / 2.5
(2)
Continuous output Q
D
according to DIN4708 kW 27 — 35 35 / 45
(2)
Maximum draw-off rate for the duration of
10min (reheating with 35kW)
(3)
l/min 21 — 22 22 / 24
(2)
Hot water quantity without reheating at 15l/min
draw-off rate
(3)
litres 200 230 230 / 405
(2)
Hot water volume with reheating with 20kW at
15l/min draw-off rate
(3)
litres 400 — 500 500 / 858
(2)
Short-term water quantity in 10min
(3)
litres 210 — 220 220 / 240
(2)
Pipe connections
Cold and hot water Inches 1"AG(outer thread)
Heating feed and return flow Inches 1"AG(outer thread)
Solar connections Inches 1"IG(internal thread)/ DN25
(1)
With post-charging at 35kW, 80°C flow temperature, 65°C storage tank temperature(T
SP
), 45°C hot water temperature(T
WW
), 10°C cold water
temperature(T
KW
).
(2)
With parallel connection of both storage tank charging heat exchangers.
(3)
With 40°C hot water temperature, 10°C cold water temperature and 60°C storage tank temp. at draw-off start.
