![Daikin EKHWP500PB [29/36] Technical data](/views2/1788416/page29/bg1d.png)
8 Technical data
Installation and operating manual
29
EKHW(D/C/P)(300/500)(P)B
Daikin Altherma ST (Hot water storage tank)
008.1633099_00 – 06/2020
8‒5 Pressurised System – P
Model Identifier (x=A, B, C, …) EKHWP300PBx EKHWP500PBx
Unit
Product data related to regulation (EU) 812/2013 and regulation (EU) 814/2013
Energy efficiency class — B
Standing loss S W 64 72
Hot water storage tank volume V litres 294 477
Specific standing loss (EN12977) (UA)
sb,s,a
W/K 1.43 1.59
Volume of the non-solar heat storage V
bu
litres 290 393
Basic data
Empty weight kg 56 82
Total filled weight kg 350 559
Dimensions (L×W×H) without switching unit
from E-Pac
cm 59.5×61.5×164.6 79×79×165.8
Tilt dimension cm 175 184
Maximum permissible storage water
temperature
°C 85
Standby heat expenditure at Δ45K kWh/24h 1.5 1.7
Domestic hot water (stainless steel 1.4404)
Potable water capacity litres 27.8 29
Maximum operating pressure bar 10
Domestic water heat exchanger surface m
2
5.6 5.9
Storage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 12.85 18.1
Heat exchanger surface area m
2
2.66 3.7
Pressurised solar heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 3.9 8.7
Heat exchanger surface area m
2
0.76 1.69
Solar heating backup (stainless steel 1.4404)
Water capacity heat exchanger litres — 3.9
Heat exchanger surface area m
2
— 0.76
Thermal output data
(1)
Volume of hot water without reheating at
draw-off rate (8l/min / 12l/min)
(T
KW
=10°C / T
WW
=40°C / T
SP
=50°C)
litres 184
(2)
/ 153
(2)
324
(3)
/ 282
(3)
288
(2)
/ 240
(2)
Volume of hot water without reheating at
draw-off rate (8l/min / 12l/min)
(T
KW
=10°C / T
WW
=40°C / T
SP
=60°C)
litres 282
(2)
/ 252
(2)
495
(3)
/ 444
(3)
Volume of hot water without reheating at
draw-off rate (8l/min / 12l/min)
(T
KW
=10°C / T
WW
=40°C / T
SP
=65°C)
litres 352
(2)
/ 321
(2)
560
(3)
/ 516
(3)
Reheating time (Wh) after a draw-off
quantity (bathtub: 140l / shower: 90l)
(T
KW
=10°C / T
WW
=40°C / T
SP
=50°C)
min 45
(4)
/ 30
(4)
25
(5)
/ 17
(5)
Pipe connections
Cold and hot water Inches 1"AG(outer thread)
Heating feed and return flow Inches 1"IG(internal thread)/ 1"AG(outer thread)
Solar connections Inches 1"AG(outer thread)
(1)
T
KW
=cold water temperature, T
WW
=hot water temperature, T
SP
=storage tank temperature at draw-off start.
(2)
Charging before tapping only by heat pump without electric immersion heater.
(3)
Charging before tapping by heat pump and electric immersion heater.
(4)
With heat pump 8kW.
(5)
With heat pump 16kW.
