![Daikin EKHWP500PB [27/36] Technical data](/views2/1788416/page27/bg1b.png)
8 Technical data
Installation and operating manual
27
EKHW(D/C/P)(300/500)(P)B
Daikin Altherma ST (Hot water storage tank)
008.1633099_00 – 06/2020
8‒3 Pressurised system – P
Model Identifier (x=A, B, C, …) EKHWCH300PBx EKHWCH500PBx EKHWCB500PBx
Unit
Product data related to regulation (EU) 812/2013 and regulation (EU) 814/2013
Energy efficiency class — B
Standing loss S W 64 72
Hot water storage tank volume V litres 294 477
Specific standing loss (EN12977) (UA)
sb,s,a
W/K 1.43 1.59
Volume of the non-solar heat storage V
bu
litres 288 322
Basic data
Empty weight kg 52 78 83
Total filled weight kg 346 555 560
Dimensions (L×W×H) cm 59.5×61.5×164.6 79×79×165.8
Tilt dimension cm 175 184
Maximum permissible storage water
temperature
°C 85
Standby heat expenditure at Δ45K kWh/24h 1.5 1.7
Drinking water heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 18.6 26.5
Maximum operating pressure bar 10
Domestic water heat exchanger surface m
2
3.8 5.32
1ststorage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 9.69 10
Heat exchanger surface area m
2
1.9 1.95
2ndstorage tank charging heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres — — 10.9
Heat exchanger surface area m
2
— — 2.2
Pressurised solar heat exchanger (stainless steel 1.4404)
Water capacity heat exchanger litres 3.9 8.7
Heat exchanger surface area m
2
0.76 1.69
Solar heating backup (stainless steel 1.4404)
Water capacity heat exchanger litres — 3.8
Heat exchanger surface area m
2
— 0.74
Thermal output data
Efficiency characteristic N
L
acc. to DIN4708
(1)
— 2.2 2.3 2.3 / 2.5
(2)
Continuous output Q
D
according to DIN4708 kW 27 35 35 / 45
(2)
Maximum draw-off rate for the duration of
10min (reheating with 35kW)
(3)
l/min 21 22 22 / 24
(2)
Hot water quantity without reheating at 15l/min
draw-off rate
(3)
litres 200 230 230 / 405
(2)
Hot water volume with reheating with 20kW at
15l/min draw-off rate
(3)
litres 400 500 500 / 858
(2)
Short-term water quantity in 10min
(3)
litres 210 220 220 / 240
(2)
Pipe connections
Cold and hot water Inches 1"AG(outer thread)
Heating feed and return flow Inches 1"AG(outer thread)
Solar connections Inches 1"AG(outer thread)
(1)
With post-charging at 35kW, 80°C flow temperature, 65°C storage tank temperature(T
SP
), 45°C hot water temperature(T
WW
), 10°C cold water
temperature(T
KW
).
(2)
With parallel connection of both storage tank charging heat exchangers.
(3)
With 40°C hot water temperature, 10°C cold water temperature and 60°C storage tank temp. at draw-off start.
