Einhell BT-SM 2131 Dual [20/148] Before starting the equipment
![Einhell BT-SM 2131 Dual [20/148] Before starting the equipment](/views2/1078968/page20/bg14.png)
A load factor of S2 5 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (1800 W) for no longer than
the time stipulated on the specifications label (5
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level 93 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 104 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 61029.
Vibration emission value a
h
= 2.44 m/s
2
K uncertainty = 1.5 m/s
2
Additional information for electric power tools
Warning!
The specified vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equipment
is used and may exceed the specified value in
exceptional circumstances.
The specified vibration value can be used to compare
the equipment with another electric power tools.
The specified vibration value can be used for initial
assessment of a harmful effect.
Reduce noise generation and vibration to a
minimum!
Use only equipment that is in perfect condition.
Maintain and clean the equipment regularly.
Adopt your way of working to the equipment.
Do not overload the equipment.
Have the equipment checked if necessary.
Switch off the equipment when not in use.
Residual risks
Even if you use this electric power tool in
accordance to instructions, certain residual risks
cannot be eliminated. The following hazards may
arise in connection with the equipment’s
construction and layout:
1. Lung damage if no suitable protective dust mask
is applied.
2. Damage to hearing if no suitable ear protection is
applied.
3. Health damage caused by hand-arm vibrations if
the equipment is used over a longer period or is
not properly guided and maintained.
6. Before starting the equipment
6.1 General information
The equipment must be set up where it can stand
securely, i.e. it should be bolted to a workbench,
a universal base frame or similar.
All covers and safety devices have to be properly
fitted before the equipment is switched on.
It must be possible for the blade to run freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws, etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
equipment’s moving parts run smoothly.
Check that the voltage on the rating plate is the
same as your supply voltage before you connect
the equipment to the power supply.
Pull out the power plug before carrying out any
assembly and adjustment work.
6.2 Assembling the saw (Fig. 1-5)
To adjust the turntable (17), loosen the locking
screw (14) by approx. 2 turns, which frees the
turntable (17).
Turn the turntable (17) and scale pointer (15) to
the desired angular setting on the dial (16) and
lock into place with the locking screw (14). The
saw has locking positions at angles of - 45°, -
31.6°, -22.5°, -15°, 0°, 15°, 22.5°, 31.6° and 45°,
at which the turntable (17) audibly clicks into
position.
To release the saw from its position at the bottom,
pull the fastening bolt (25) out of the motor
mounting while pressing down lightly on the
machine head (4). Turn the fastening bolt (25)
through 90° before releasing it, so that the saw
remains unlocked.
Swing the machine head (4) up until the release
lever (3) latches into place.
The clamping device (8) can be fitted on the left
20
GB
Anleitung_BT_SM_2131_Dual_SPK7:_ 14.10.2010 15:39 Uhr Seite 20
