Evolution X-Session Advanced User Guide
2
In the X-Session Advanced Guide we have made the assumption that you have been
through the X-Session Getting Started Guide which should have been supplied in printed
form with your X-Session. If you do not have this guide, please contact your local distribu-
tor or download it from our website www.evolution.co.uk
The Getting Started Guide should insure that you are now familiar with the basic op-
eration of the X-Session so that we now can focus on more in-depth features.
First however, we need to explain some terminology we use throughout the guide.
Edit Mode
:
Edit Mode describes the short period after a function button has been pressed during
which the parameters of that function can be altered. The numeric keypad can be
used to alter a parameter during this time. No data is sent out of the X-Session when it is
in Edit mode except for program and bank changes. LCD symbols shown in Edit mode
will flash to show you that a particular parameter can be edited. If a number is part
entered, and a new controller turned, that number will become the relevant parameter
number for the new controller and the 3 second editing period will re-trigger.
Default mode
:
Default Mode describes the state of the X-Session, when no function buttons have been
pressed within the last 3 seconds. In Default mode, the LCD will show the controller
symbol, and the 2 digit display will show the last selected controller. The 3 digits
display the currently assigned MIDI CC number.
About The Advanced Guide
Terminology
31
Evolution X-Session Advanced User Guide
Appendix F - Roland GS and Yamaha XG NRPN Sup-
port to Roland JV/XP
NRPN NRPN Data Data
MSB LSB MSB LSB
CC99 CC98 CC06 CC38
01 08 00-7F n/a (-64 - 0 - +63) Vibrato Rate (relative change)
01 09 00-7F n/a (-64 - 0 - +63) Vibrato Depth (relative change)
01 0A 00-7F n/a (-64 - 0 - +63) Vibrato Delay (relative change)
01 20 00-7F n/a (-64 - 0 - +63) Filter Cutoff Freq. (relative change)
01 21 00-7F n/a (-64 - 0 - +63) Filter Resonance (relative change)
01 63 00-7F n/a (-64 - 0 - +63) EG (TVF&TVA) Attack Time (relative change)
01 64 00-7F n/a (-64 - 0 - +63) EG (TVF&TVA) Decay Time (relative change)
01 66 00-7F n/a (-64 - 0 - +63) EG (TVF&TVA) Release Time (relative change)
*14 00-7F 00-7F n/a (-64 - 0 - +63) Drum Filter Cutoff Freq. (relative change)
*15 00-7F 00-7F n/a (-64 - 0 - +63) Drum Filter Resonance (relative change)
*16 00-7F 00-7F n/a (-64 - 0 - +63) Drum EG Attack Rate (relative change)
*17 00-7F 00-7F n/a (-64 - 0 - +63) Drum EG Decay Rate (relative change)
18 00-7F 00-7F n/a (-64 - 0 - +63) Drum Instrument Pitch Coarse (relative change)
*19 00-7F 00-7F n/a (-64 - 0 - +63) Drum Instrument Pitch Fine (relative change)
1A 00-7F 00-7F n/a (0 to Max) Drum Instrument Level (absolute change)
1C 00-7F 00-7F n/a (Random, L>C>R) Drum Instrument Panpot (absolute change)
1D 00-7F 00-7F n/a (0 to Max) Drum Instrument Reverb Send Level (absolute change)
1E 00-7F 00-7F n/a (0 to Max) Drum Instrument Chorus Send Level (absolute change)
%1F 00-7F 00-7F n/a (0 to Max) Drum Instrument Variation Send Level (absolute change)
* = added by Yamaha XG; % changed from Delay to Variation by Yamaha XG
Appendix G - General MIDI Reverb and Chorus
Types
Reverb Types
0: Small Room
1: Medium Room
2: Large Room
3: Medium Hall
4: Large Hall
8: Plate
Chorus Types
0: Chorus 1
1: Chorus 2
2: Chorus 3
3: Chorus 4
4: FB Chorus
5: Flanger
