Evolution X-Session Advanced User Guide
26
B2-The Buttons:
MIDI CC Description Program
(Press Twice)
Data Lsb
(Press Twice)
Data Msb
(Press Twice)
0-119 Standard MIDI CC’s - Toggle Value 2 Toggle Value 1
120-127 Channel Mode
Messages
- Toggle Value 2 Toggle Value 1
128 Pitch Bend Range - Sensitivity value -
129 Channel Fine Tune - Tuning amount -
130 Channel Coarse Tune - Tuning amount -
131 Channel Pressure - Pressure amount -
132 RPN Coarse Value RPN LSB RPN MSB
133 RPN Fine Value RPN LSB RPN MSB
134 NRPN Coarse Value NRPN LSB NRPN MSB
135 NRPN Fine Value NRPN LSB NRPN MSB
136 Master Volume GM* - Volume LSB Volume MSB
137 Master Pan GM* - Pan LSB Pan MSB
138 Master Coarse Tune
GM*
- Tuning LSB Tuning MSB
139 Master Fine Tune
GM*
- Tuning LSB Tuning MSB
140 Chorus Mod rate
GM2*
- Mod rate -
141 Chorus Mod Depth
GM2*
- Mod depth -
142 Feedback GM2* - Feedback level -
143 Send to Reverb GM2* - Reverb send
level
-
144 Pitch Bend - Pitch shift LSB Pitch shift MSB
145 Program/Bank Preset Program Bank LSB Bank MSB
146 MIDI CC (on/off) MIDI CC Button press
value
Button release
value
147 Note (on/off) Note Velocity off Velocity on
148 Note (on/off toggle) Note Velocity off Velocity on
149
MMC Command** - Command select. -
150
Reverb type GM2 * - Type -
151
Reverb time GM2 * - Time -
152
Chorus type GM2* - Type -
255
Controller Off***
- - -
* Sysex messages - for details please see pages 8 & 18.
** MMC Sysex messages, for details please see page 11.
*** This value cannot be typed in using the numerical keypad. Type in 144 and
then press the '+' button to set this value, or 0 and press the '-' button.
7
Evolution UC-33 Advanced User Guide
Programming
&
Editing
