Pioneer CD-PC1 [15/32] Creating a wipe display animation

x Click “Capture” to capture the images.

Captured images will be displayed in the preview.

Note:

• Capture images can be checked in the preview. Use the Playback (3), Pause (8), Stop (7) and

Repeat ( ) buttons to control the playback of the captured images.

• Captured images can be processed (converted or corrected). (Images are saved using a file for-

mat that cannot be processed. Always process images before saving.)

Creating a Wipe Display Animation

Select “Wipe” using steps z – c of “Selecting the Animation to Create”.

The selected image will be automatically set as the “Foreground”.To select the background image,

click “Display Background” and select the image file.

q Frame: Image position for both foreground and background can be

set. (See “Changing the Frame Position and Size” on page

11.)

w Foreground/Background

Select Button: The image displayed in the main view can be switched

between the foreground (the image displayed first) and back-

ground (the later displayed image).

e Direction Setting button: The direction to wipe (repaint) can be set.

r Frame numbers: The frame numbers when wiping the foreground image and

background image is displayed. Click the “5” or “∞” button to

set the capturing frame numbers (1 – 60). (Maximum is about

4 seconds.)

t “Capture”: Captures the set images.

Continued overleaf.
