Quitting the Program
z Click “Close ” on the top right of the screen.
The program will end and the window will close.
Returning Car Audio Images to
Factory Settings
Rewritten car audio images can be returned to the images at the time of purchase.
z Click “Open ”.
A dialog box will appear.
x Select “Pioneer” – “LinkKit” – “Sample”.
If the install directory is not specified at the time of install, the “Pioneer” folder will be
installed in the Program Files folder.
c Select the image file and click “Open”.
The selected image will be displayed in the preview.
v Write the selected image to the front panel.
Follow “Connecting the Front Panel for Communication” for performing operation.
Note:
• You can also download images (factory settings) from the Pioneer homepage.
29
