Product Contents
This product package contains the items shown below. Check to make sure no items are missing
upon opening the box.
• PC LinkKit main unit
• CD-ROM
• AC adapter
• Power cord
• RS-232C cable (Part No.: CZD6031)
• Owner’s manual (this manual)
• Warranty card (for European, U.S. and Canadian models)
Main Features
Car audio movies and still images compatible with this product can be created, downloaded, and
saved using a PC. In addition, desired images downloaded can be written to the car audio system
for display during playback.
There are 3 types of images that can be rewritten.
• Movie screen (MOVIE)
• Level indicator (Indicator)
• Background still picture (BGP)
Note:
• Background visuals (BGV) cannot be created/rewritten.
• The level indicator cannot be created.The level indicator images can only be rewritten by downloading
from the LinkKit Website.
Caution:
• Pioneer will not be responsible for any loss or damage to data resulting from the use of this prod-
uct or PC.
