VIA VT6410 IDE RAID Drives Configuration - 4 -
Ác
Åé
¤¤
¤å
Step 3:
Set First Boot Device under the Advanced BIOS Features menu to CD-ROM to boot from CD-ROM
after system restarts (Figure 3).
Step 4:
Save and exit BIOS Setup.
Figure 3
Step 2:
Select Hard Disk Boot Priority under the Advanced BIOS Features menu and then choose the
model of the IDE hard drive onto which you want to install Microsoft Windows 2000/XP (Figure 2).
Figure 2
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Hard Disk Boot Priority
1. SCSI-0 : Maxtor 6E030L0
2. SCSI-1 : Maxtor 6E030L0
3. Bootable Add-in Cards
KL: Move PU/PD/+/-: Change Priority F10: Save ESC: Exit
Item Help
Menu Level ``
Use <K> or <L> to
select a device, then
press <+> to move it
up, or <-> to move it
down the list. Press
<ESC> to exit this
menu.
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Advanced BIOS Features
` Hard Disk Boot Priority [Press Enter]
First Boot Device [CDROM]
Second Boot Device [Hard Disk]
Third Boot Device [CDROM]
Password Check [Setup]
CPU Hyper-Threading [Enabled]
Limit CPUID Max. to 3 [Enabled]
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
Select Hard Disk Boot
Device Priority
