VIA VT6410 IDE RAID Drives Configuration- 9 -
D.Serial Number View:
Highlight the Serial Number View item in main menu and press ENTER. Use the arrow key to select
a hard drive. User can see the serial number of the selected drive at last column. Serial number is
assigned by manufacturers of hard drives.
Figure 12
E.View Array Status:
Press the F1 key to show the array status on the lower screen. If there are no disk arrays then nothing
will be displayed on the screen (Figure 13).
Figure 13
VIA Tech. RAID BIOS Ver 2.11
View the serial number of
hard disk, it is useful for
identify same model disks
F1 : View Array/disk Status
KK
KK
K ,
LL
LL
L : Move to next item
Enter : Confirm the selection
ESC : Exit
XX
XX
X Create Array
XX
XX
X Delete Array
XX
XX
X Create/Delete Spare
XX
XX
X Select Boot Array
XX
XX
X Serial Number View
Channel Drive Name Array Name Mode Size(GB) Status
[*] Channel0 Master Maxtor 6E030L0 ARRAY 0 ATA 133 28.63 Stripe0
Channel0 Slave No Drive
[*] Channel1 Master Maxtor 6E030L0 ARRAY 0 ATA 133 27.24 Stripe1
Channel1 Slave No Drive
Serial Number: E1A6698E
