![Gigabyte GA-8I915P Duo Pro [5/14] 3 configuring raid set in raid bios](/views2/1267887/page5/bg5.png)
VIA VT6410 IDE RAID Drives Configuration- 5 -
(3) Configuring RAID set in RAID BIOS
To create RAID on the VT6410 controller, you have to enter the RAID setup utility. Skip this step and
proceed with Section 4 on page 10 if you do not want to create RAID.
Step 1:
After the Power-On Self-Test (POST) memory test begins and before the operating system boot begins,
look for a message which says "Press <Tab> key into User Window"(Figure 4). Hit the TAB key to enter
the RAID setup utility.
Figure 4
Step 2:
After you press the TAB key, a screen similar to that below will appear (Figure 5).
You can press the UP and DOWN ARROW keys to highlight the option you need.
Figure 5
VIA Technologies, Inc. VIA VT6410 RAID BIOS Setting Utility V2.11
Copyright (C) VIA Technologies, Inc. All Right reserved.
Press <Tab> key into User Window!
Scan Devices, Please wait...
Primary Master : Maxtor 6E030L0
Primary Master : No Device
Secondary Master : Maxtor 6E030L0
Secondary Master : No Device
XX
XX
X Create Array
XX
XX
X Delete Array
XX
XX
X Create/Delete Spare
XX
XX
X Select Boot Array
XX
XX
X Serial Number View
VIA Tech. RAID BIOS Ver 2.11
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master Maxtor 6E030L0 ATA133 28.63 Hdd
Channel0 Slave No Drive
Channel1 Master Maxtor 6E030L0 ATA133 27.24 Hdd
Channel1 Slave No Drive
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1 : View Array/disk Status
KK
KK
K ,
LL
LL
L : Move to next item
Enter : Confirm the selection
ESC : Exit
