Gigabyte GA-8I915P Duo Pro [6/14] Ác åé
![Gigabyte GA-8I915P Duo Pro [6/14] Ác åé](/views2/1267887/page6/bg6.png)
VIA VT6410 IDE RAID Drives Configuration - 6 -
Ác
Åé
¤¤
¤å
Figure 6
A.Create Array:
Use the UP and DOWN ARROW keys to highlight the Create Array command and press ENTER to call
out the list of creation steps as shown in Figure 6 below.
Figure 7
The first step is to set the RAID mode. Highlight the Array Mode option and press ENTER and a list of
RAID modes will appear (Figure 7), including RAID 0 for performance, RAID 1 for data protection,
RAID 0/1, and RAID SPAN for capacity. Use the UP and DOWN ARROW keys to highlight the RAID
mode you want to create and press ENTER to confirm the selection.
VIA Tech. RAID BIOS Ver 2.11
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master Maxtor 6E030L0 ATA 133 28.63 Hdd
Channel0 Slave No Drive
Channel1 Master Maxtor 6E030L0 ATA 133 27.24 Hdd
Channel1 Slave No Drive
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1 : View Array/disk Status
KK
KK
K ,
LL
LL
L : Move to next item
Enter : Confirm the selection
ESC : Exit
XX
XX
X Auto Setup For Performance
XX
XX
X Array Mode RAID 0 (Striping)
XX
XX
X Select Disk Drives
XX
XX
X Block Size 64K
XX
XX
X Start Create Process
VIA Tech. RAID BIOS Ver 2.11
Channel Drive Name Array Name Mode Size(GB) Status
Channel0 Master Maxtor 6E030L0 ATA 133 28.63 Hdd
Channel0 Slave No Drive
Channel1 Master Maxtor 6E030L0 ATA 133 27.24 Hdd
Channel1 Slave No Drive
Create a RAID array with
the hard disks attached to
VIA RAID controller
F1 : View Array/disk Status
KK
KK
K ,
LL
LL
L : Move to next item
Enter : Confirm the selection
ESC : Exit
XX
XX
X Auto Setup For Data Security
XX
XX
X Array Mode RAID 0 (Striping)
XX
XX
X Select Disk Drives
XX
XX
X Block Size 64K
XX
XX
X Start Create Process
RAID 0 for performance
RAID 1 for data protection
RAID 0/1
RAID SPAN for capacity
