6
BEFORE USING
THE APPLIANCE
Thoroughly read these instructions.
Remove all packing materials from the appli-
ance.
Wipe the appliance body with soft damp cloth,
thoroughly wash all the appliance parts coming
into contact with food.
OPERATING INSTRUCTIONS
1. Place the juice extractor on dry level sur-
face. Make sure than the switch (11) is in the
«0» position.
2. Install the pulp container (12), by matching
the projections on the appliance body with
grooves on the pulp container (Figure B).
3. Put the separating unit (5) on the juice ex-
tractor body (10).
4. Put the grater/filter (4) on top of the separating unit (5) so
that it completely fits into the separating unit (5) and is fixed on
the motor unit (7). Check that the grater/filter (4) rotates
freely. Put the lid (3) on top.
Note: during disassembly always remove the grater/filter
(4) together with the separating unit (5).
5. Insert the feeder tube (2) into the lid opening matching the
projections on the feeder tube with the lid grooves and lock
the feeder tube (2) by turning it counterclockwise. The hook
on the feeder tube should face the safety lock (9).
6. Lift the safety lock (9) so that it locks on the hook of the feeder
tube (2).
Note: the juice extractor has a safety system. If the safety
lock (9) is not securely fastened, the appliance will
not operate.
7. Place the juice cup (13) under the separating unit’s spout (6).
If desired, you can use for juice collecting any suitable.
Disassembly
1. Make sure that the appliance is switched off and unplugged
from electrical outlet.
2. Lower the safety lock (9) holding the safety lock button (8).
3. Remove lid (3) together with the feeder tube (2). Take out the
feeder tube (2) by turning it clockwise. Then remove the sepa-
rating unit (5). The grater/filter (4) comes away together with
the separating unit.
4. Unfasten the pulp container (12).
