35
deen
Dispensing hot water
r
!
Risk of burns
The milk frother 10 gets very hot. After use,
allow to cool down first before touching.
The appliance must be ready for use.
Place the pre-warmed cup or glass under
the outlet of the milk frother 10.
Select the required setting for hot water
Ê
by turning the knob 6.
Press the
start
button 8. Hot water runs
out of the milk frother outlet 10 for about
40 seconds.
Press the
start
button 8 again to cut the
process short.
N.B.: It is possible to set the temperature of
the hot water (see “Controls, °
C
button”).
Maintenance and daily
cleaning
r
!
Risk of electric shock
Unplug the appliance before cleaning it.
Never immerse the appliance in water.
Do not use a steam cleaner.
Wipe the outside of the appliance with a
damp cloth. Do not use scouring agents.
Rinse the water tank 11 and the brewing
unit 24 with water only.
The cover of the storage compartment
26, the drip tray panel 27 and the
insulating cover of the milk container 34
should only be wiped gently with a damp
cloth.
Do not put them in the dishwasher.
Remove the grate for the coffee outlet 29,
the grate for the milk frother 31 and the
drip tray for the milk frother 30. Take out
the drip tray for coffee outlet 28 with the
coffee grounds container 32 by pulling
them out forward, empty and clean. All
these parts can also be cleaned in the
dish washer.
●
●
●
●
●
●
●
●
Clean the measuring spoon 14, aroma
cover 16 and the inside and cover of the
milk container 34 by hand or in the dish
washer.
Wipe out the inside of the appliance (tray
holders).
Important:
Drip trays 28/30 should be
emptied and cleaned daily to prevent mould
from developing.
N.B.: If the appliance is cold when switched
on with the a button 2, or if it is set to a
mode after brewing coffee, it rinses
automatically, in other words the system
cleans itself.
Cleaning the milk system 10
Clean the milk system 10 immediately after
use!
The milk system 10 can be pre-cleaned
automatically.
Select the
Ì
symbol in the display 5 and
press the
start
button 8.
PLACE EMPTY GLASS UNDER FROTHER,
P
LACE SUCTION PIPE IN GLASS
Ò
START
Place an empty glass under the milk
system 10 and put the end of the pipe
10d in the glass.
Press the
start
button 8. The appliance
now fills the glass automatically with
water and draws it in again through the
pipe 10d for cleaning. The rinse
procedure stops automatically after about
1 minute.
Now empty the glass and clean the pipe
10d.
In addition to this, clean the milk system
thoroughly once every two weeks or so (by
hand or in the dishwasher).
Dismantling the milk system 10 for
cleaning:
Pull the milk system 10 forward out of the
appliance.
Clean the individual parts (Fig. C) with a
detergent solution and a soft brush.
●
●
●
●
●
●
●
●
SE_TK76_Teil_1_080917.indd 35 18.09.2008 08:40:49
