9. ELECTRICAL WIRING WORK

〈

CAUTION

〉

To the electrician

Install the earth leakage breaker which can handle harmonics.

(This unit has an inverter, so an interrupter capable of handling harmonics is needed to prevent malfunction

of the interrupter itself.)

Do not run the unit until the refrigerant charging is complete.

work, in accordance with the national law and installation manual.

• The wiring between the

indoor unit and outdoor unit must be for 230V.

• The electrical wiring work should be done in accordance with the Electrical Wiring Diagram Label.

• When doing the electrical wiring, always shut off the power source before working, and do not turn on the

branch switch until all work is complete.

• By installing the earth leakage breaker, a protective earth resistance value of 500 ohms is applied.

• Do not let the earth wire should come in contact with gas pipes, water pipes, lighting rods, or telephone

earth wires.

· Gas piping: there is a h

• Never attach a phase advancing capacitor for improving the power factor. (Not only will this not improve the

power factor, but it might cause abnormal heat.)

• Be sure to use earth leakage breake

break switch with fuse or breaker for wiring.

• For wiring, use the designated power wire and connect firmly, then secure to prevent outside pressure

being exerted on the terminal board (power supply wiring, transmission wiring, earth wiring).

• The power wiring should be connected in a positive phase.

• Left-over wiring should not be wrapped and stuffed into the unit.

• To prevent the power wiring from being damaged by the knock hole edges, put it in a wir

• Make sure the wiring and the control box lid do not stick up above the structure, and close the cover firmly.
