27 English
11. ON SITE SETTINGS
〈
WARNING
〉
Always close the front panel when leaving the outdoor unit with the power on.
The functions of the outdoor unit can be set using the remote controller.
During installation, make the on-site settings according to the description below, after the service inspection
and repair.
Mistakes in the settings could cause malfunctions.
How to make the on-site settings
Make the on-site settings according to “How to make the on-site settings” which came with the remote controller.
• The settings are set by switching between “Mode No.”, “FIRST CODE NO.”, and “SECOND CODE NO.”.
Content of settings and setting number
:Factory settings
See the technical guide for details on the content of the settings.
NOTES
1.
Settings are done in a batch for the group. For this reason, when performing group control* using the
remote controller from one unit to set individual outdoor units, set each unit separately (for each connected
indoor unit NO.) using the mode number in parentheses. Checking after changing settings can also only be
done using the mode numbers in parentheses. (For group batch control, the display will always read “01”
even though the settings have been changed.) Furt
hermore, when performing control with two remote
controllers*,
on-site settings using a remote controller can only be done using the main remote controller.
* For details on controlling the units using the remote controllers, see applicable technical guides.
2. Do not set any values not shown in the table above.
3. When returning to normal mode, the remote controller may display “88” because it has been initialized.
Mode
No.
FIRST
CODE NO.
Content of settings
SECOND CODE NO.
01 02
16 (26)
0
Select from “Low Night Noise Setting”, “Performance
Priority Setting”.
–
Low Night Noise
Setting
1
You can set “starting time”, and “ending time” for
the Low
Night Noise Setting.
SECOND CODE NO.
03 04 05
Performance
Priority Setting
Low Night Noise
Setting
+
Performance Priority
Setting
10 pm - 6 am 10 pm - 8 am 8 pm - 8 am
[Mode switching]
Normal operating mode
Test run
Measures
On-site setting
(Press
4 seconds
or more)
Once
Once
Once
Once Once
Once
Once
“Malfunction code”
display
“Indoor unit type
code” display
“Outdoor unit type
code” display
*
**
* After leaving 10 seconds or
more, the mode returns to
the normal operating mode.
01_EN_3P281953-1B.fm Page 27 Tu esday, January 25, 2011 3:35 PM
