4. Technical data
Voltage: 400 V 3 ~ 50 Hz
Power rating: 3600 W S2 15 min
Idle speed: 2950 rpm
Protection type: IP 54
Max. splitting force: 8 t
Splitting lift: 480 mm
Splitting speed
Downwards: 0.032 m/s
Upwards: 0.12 m/s
Trunk holding capacity:
Diameter: 50 -400 mm
Length: 100 -1040 mm
Oil quantity: 4 l
Weight: 105 kg
L
pA
sound pressure level 87 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 100 dB(A)
Vibration emission value a
hw
< 2,5 m/s
2
Load factor:
A load factor of S2 15 min (intermittent periodic duty)
means that you may operate the motor continuously
at its nominal power level (3600 W) for no longer than
the time stipulated on the specifications label (15
minutes ON period). If you fail to observe this time
limit the motor will overheat. During the OFF period
the motor will cool again to its starting temperature.
5. Before starting the equipment
5.1 Fitting the switch/plug combination (Fig. 3)
Install the switch/plug combination on the wood
splitter as shown in Figure 3. Use the four screws
(Fig. 2 / Item 13) for this purpose.
5.2 Fitting the transport handle (Fig. 4/5)
Remove the two screws in the transport handle using
an Allen key (Fig. 4). Place the transport handle over
the two holes in the cover on the rear cover of the
wood splitter and secure it with the two screws as
shown in Figure 5.
5.3 Fitting the wheels (Fig. 6-10)
Push a split pin (Fig. 2/Item 16) through one of the
holes in the axle (Fig. 2/Item 14) and bend it as
shown in Figure 6. Now slide a washer (Fig. 2/Item
15) and a wheel (Fig. 2/Item 7) over it (Fig. 7). Guide
the axle through the holes provided for it at the
bottom on the rear of the wood splitter (Fig. 8). Now
place the remaining wheel and washer on the axle
(Fig. 9) and secure it with the other split pin (Fig. 10).
5.4 Fitting the control lever and hand guards (Fig
11a-14)
Remove the pre-assembled securing screws from the
two hand guards by undoing the nuts and removing
the screws as shown in Figure 11a. Guide the hand
guards and control level, as shown in Figure 11b,
from the front into the wood splitter so that the ends of
the control lever project through the recesses
provided for it in the control rods (Fig. 12). Then
secure the hand guards using the previously
unassembled securing screws as shown in Figure 13
– 14a. The safety bars (Item 22) and guard plates
(Item 19) are fitted to the hand guards (Item 3) as
shown in Figures 14b-14d.
5.5 Fitting the trunk holding plates (Fig. 15a-18)
Undo the star nuts on the two trunk holding plates
(Fig. 2/Item 11) by turning these counter-clockwise as
shown in Figure 15a. You now have the trunk holding
plates, star nut A, washer B and fastening screw C
(Fig. 15b). Push the trunk holding plates through the
guide slots in the hand guards, as shown in Figure 16.
As you do this, ensure that the oval holes in the trunk
holding plates line up with the securing holes. Insert
the securing screws A from below through the oval
holes in the trunk holding plates and the holes in the
hand guards as shown in Figure 17 and secure then
by fitting the washers B and star nuts C to them from
above (Fig. 18). The trunk holding plates can be
adjusted to the trunk thickness using the oval holes.
5.6 Fitting the chain to adjust the splitter height
(Fig. 19-21)
First undo the lock nut on the chain hook (Fig. 19).
Secure the chain hook to the hole provided for it next
to the chain holder behind the splitter as shown in
Figure 20. The chain is designed to limit the height of
the splitter. To do this, move the splitter
approximately to the required position, switch off the
machine (Fig. 29) and attach the chain in the
appropriate position (Fig. 21).
5.7 Fitting the trunk support (Fig. 22-26)
The trunk support can be installed at three different
heights (Fig. 22):
Position A: Max. log length 520 mm
Position B: Max. log length 770 mm
Position C: Max. log length 1040 mm
There are three attachment devices at different
heights on the wood splitter for this purpose. To use
the trunk support, the locking levers on the
appropriate attachment device must be moved
