8 DIFETTI
8.1 Visualizzazione dell'ultimo difetto
Utilizzare il tasto per spegnere l'unità, quindi premere il pulsante .
Il LED rosso di difetto presente rimane acceso fisso e sul display della temperatura viene indicato il codice guasto più recente.
Se l'unità non ha mai rilevato un difetto di bloccaggio, non verrà visualizzato alcun codice.
È possibile cancellare l'ultimo difetto di bloccaggio premendo per un breve istante il pulsante mentre si tiene premuto il pulsante .
8.2 Codici difetto
Se il LED di difetto presente lampeggia, il dispositivo di comando della caldaia ha rilevato un guasto. Sul display della temperatura verrà
visualizzato un codice difetto.
Una volta rettificato il difetto, il dispositivo di comando della caldaia può essere riavviato premendo il pulsante di reset.
Possiamo distinguere tra i tipi di guasto seguenti:
Display della
temperatura
Descrizione Causa possibile/soluzione
•
L'unità è spenta.
10, 11, 12, 13, 14 Guasto sensore S1
•
Presenza di aria nell'impianto. Spurgare l'aria dalla caldaia e dall'impianto CH.
• Controllare che il cablaggio non sia interrotto.
• Sostituire il sensore S1.
20, 21, 22, 23, 24 Guasto sensore S2
•
Controllare che il cablaggio non sia interrotto.
• Sostituire il sensore S2.
0 Guasto al sensore dopo l'auto-
controllo
•
Sostituire il sensore S1 e/o S2.
1 Temperatura troppo alta
•
Presenza di aria nell'impianto. Spurgare l'aria dalla caldaia e dall'impianto CH.
• La pompa non sta funzionando. Controllare il cablaggio tra la pompa e il
dispositivo di comando della caldaia.
• Flusso insufficiente nell'impianto, radiatori chiusi, impostazione pompa troppo
bassa.
2 Scambiare il sensore S1 e S2
•
Controllare il cablaggio.
• Sostituire il sensore S1 o S2.
4 Nessun segnale della fiamma
•
Valvola principale del gas non aperta.
• Pressione di alimentazione del gas troppo bassa o scompare.
• Uscita della condensa ostruita.
• Controllare l'unità di accensione e il relativo cavo.
• Distanza tra gli elettrodi assente o non corretta.
• Il blocco del gas o l'unità di accensione non ricevono corrente elettrica.
• Controllare la messa a terra.
5 Segnale scarso della fiamma
•
Uscita della condensa ostruita.
• Pressione di alimentazione del gas troppo bassa o scompare.
• Controllare l'unità di accensione e il relativo cavo.
• Controllare l'impostazione del blocco del gas.
• Controllare la messa a terra.
• Controllare l'alimentazione dell'aria e l'uscita del gas, verificando l'eventuale
presenza di un ricircolo dei fumi.
6 Errore nella rilevazione della
fiamma
•
Sostituire il cavo dell'accensione + il cappuccio della candela.
• Sostituire l'unità di accensione.
• Sostituire il sistema di comando della caldaia.
8 Il regime di giri della ventola non
è corretto
•
La ventola spinge contro l'isolante del coperchio.
• Cablaggio tra ventola e coperchio.
• Controllare che il cablaggio non presenti contatti difettosi.
• Controllare e/o sostituire la ventola.
• Sostituire il sistema di comando della caldaia.
27 Cortocircuito del sensore
temperatura esterna
•
Controllare il cablaggio del sensore temperatura esterna.
• Sostituire il sensore temperatura esterna.
• Il relè del bruciatore non è adatto per quest'applicazione.
• Sostituire il dispositivo di comando della caldaia con la versione appropriata.
29, 30 Guasto al dispositivo di
comando valvola del gas
•
Sostituire il sistema di comando della caldaia.
Sostituire solo le parti guaste usando esclusivamente parti Daikin originali.
La mancata installazione, o il montaggio errato dei sensori S1 e/o S2 possono causare gravi danni.
