EKHY075787 / EKPS075867 / EKPS075877 / EKPS075917
EKPS076197 / EKPS 076207 / EKPS076217 / EKPS076227
Conversion Instructions
Contents:
Gas metering ring (for diameter see table below)
1
Conversion instruction manual
1
O-ring 19*2
1
Sticker gas type / gas supply pressure
2
THE APPLIANCE IS FOR USE WITH NATURAL GAS OR LPG. (Cat II 2H3P)
These instructions must be read in conjunction with the installation & servicing instructions. This conversion may only
be carried out by a competent person and has to be in accordance with local or national standards that apply when
converting to another gas type.
It must NOT be attempted unless the person carrying out the conversion is equipped with a combustion analyser and is
competent in its use.
ISOLATE MAINS ELECTRICAL SUPPLY AND REMOVE OUTER CASE AS SHOWN IN THE INSTALLATION, COMMISSIONING &
SERVICING INSTRUCTIONS.
Important: Do not install the appliance into a room or internal space below ground level when it is intended for use with LPG (propane – G31).
This does not apply to basements that are open on at least on side.
Installation Regulations
In addition to those specified in the installation and operation manual of the boiler, the following local or national standard apply.
All conversions require the air/gas ratio to be set correctly in accordance with the gas that will be used. The procedure for setting the
air/gas ratio is included in these instructions.
1 BOILER CONFIGURATION
Table 1, inserts and associated gas ring for conversion to G31
Gas category:
Propane P
G31, 30/37/50 mBar
Article no.
conv. set
Insert model
Applicable for boiler models
Gas ring
EKPS075917
541
EHOB12AAV1, EHOBG12AAV1
RHOB12AAV1, RHOBG12AAV1
315
EKPS075877
471
EHOBG18AAV1, EKOMBG22AAV1, EKOMBGU22AAV1,
RHOBG18AAV1, RKOMBG22AAV1
410
EKPS075867
406
EHOB18AAV1, EKOMB22AAV1, EKOMBG28AAV1, EKOMBGU28AAV1
RHOB18AAV1, RKOMB22AAV1, RKOMBG28AAV1
480
EKHY075787
362
EKOMB28AAV1, EKOMB33AAV1, EKOMBG33AAV1, EHOB42AAV1
EKOMBGU33AAV1
RKOMB28AAV1, RKOMB33AAV1, RKOMBG33AAV1, RHOB42AAV1
EHYKOMB33AA, RHYKOMB33AA
525
Table 2, inserts and associated gas ring for conversion to G25
Gas category
Natural gas H
G25, 25 mBar
Article no.
conv. set
Insert model
Applicable for boiler models
Gas ring
EKPS076197
541
EHOB12AAV1, EHOBG12AAV1
RHOB12AAV1, RHOBG12AAV1
620
EKPS076207
471
EHOBG18AAV1, EKOMBG22AAV1, EKOMBGU22AAV1,
RHOBG18AAV1, RKOMBG22AAV1
550
EKPS076217
406
EHOB18AAV1, EKOMB22AAV1, EKOMBG28AAV1,
EKOMBGU28AAV1
RHOB18AAV1, RKOMB22AAV1, RKOMBG28AAV1
650
EKPS076227
362
EKOMB28AAV1, EKOMB33AAV1, EKOMBG33AAV1, EHOB42AAV1
EKOMBGU33AAV1
RKOMB28AAV1, RKOMB33AAV1, RKOMBG33AAV1, RHOB42AAV1
EHYKOMB33AA, RHYKOMB33AA
720
