• Daikin Altherma Low Temperature • Monobloc • EBLQ011-016BA6V3

4 Capacity tables

4 - 2 Cooling capacity tables

EBLQ-B6V3

Maximum Cooling Capacity

3TW58012-1C

SYMBOLS

CC : Cooling capacity at maximum operating frequency, measured acc.

Eurovent 6/C/003-2006 (kW)

HC : Heating capacity at maximum operating frequency, measured acc.

Eurovent 6/C/003-2006 (kW)

PI :

Power input (kW), measured acc. Eurovent 6/C/003-2006 (kW)

LWE : Leaving Water Evaporator temperature (°C)

LWC : Leaving Water Condensor temperature (°C)

Tamb : Ambient temperature RH=85%

Heating capacity at heat recovery condenser

1 Cooling capacity

Capacity is according to Eurovent rating standard 6/C/003-2006 and valid for chilled water

range Dt = 3∼8°C

Capacity values may not be extrapolated below 7°C leaving water temperature

2 Heating capacity

Capacity is according to Eurovent rating standard 6/C/003-2006 and valid for chilled water

range Dt = 3∼8°C

3 Power input

Power input is total of indoor and outdoor unit, except the circulation pump; according to

Eurovent rating standard 6/C/003-2006.

Pump power input to be added = 90 W (according EN14511).

NOTES:

-For the model with heatertape (*(D:V)LQ): when ambient temperature becomes lower than ’X’:

bottomplate heater power input to be added = 95W

1) For AA models: ’X’ = 4°C

2) For BA models: ’X’ = [F-02] = BPH ON temp for more details see installationmanual

of indoor unit.

NOTES

(a) only E(D/B)L*
