Bomann WA 9312.1 [11/16] Ashing
![Bomann WA 9312.1 [11/16] Ashing](/views2/1080422/page11/bgb.png)
11
05/2012
Eco
As for the short washing cycle temperature and amount of water for prewash and main wash cycle are
reduced, rinsing takes less water and in general less energy is consumed. This function must be set
before starting the washing machine. This function is only available for cotton, synthetic, delicate and
prewash cycles.
Intensiv
For better results the main wash cycle is extended.
Except for short wash, rinse and spin this function can be selected for all washing cycles. This
washing program is recommended for baby clothes or persons with allergies.
Crease protection
No pumping or spinning after the last washing cycle in this function.
You can select the crease protection function for all programs except for wash, rinse and spin. Please
note: Iron your clothes to remove creases completely.
Please note: eco + children’s wear or eco + intensive cannot be selected together.
■ Change the washing program
You have two options to change a running program:
1. Press the Start/Pause button, change the program and press Start/Pause again. After sev-
eral minutes the program will change.
2. Press the Start/Pause button and set the program selector to the position “Aus” (Off). Then
you can select another program and restart the device immediately by pressing the
Start/Pause button.
Bubble Removal Function:
Bubble Check Function: Redundant bubbles will occur when there is excessive detergent, which will
affect Wash and Rinse effects. The procedure will check automatically and one bubble removal proce-
dure will be added automatically to remove bubbles when excessive bubbles are checked. It will also
remind the user to use less detergent during the next similar washes.
Child lock:
The appliance comes with a child lock function to avoid operating errors caused by playing children.
After starting the device press and hold the buttons spin and delay for 3 seconds to lock special
functions, start/pause and the program selector; you will hear an acoustic signal.
Press and hold again for 3 seconds to deactivate the child lock. You will again hear an acoustic signal.
At the end of the washing cycle the child lock is automatically deactivated. With activated child lock
invalid operation is signaled with an acoustic signal.
TABLE OF WASHING PROCEDURES
Program Temp.
kg
Textiles
Detergent
Time
(min)
max. spin speed
(rpm)
Box
I
Box
II
Box
WA
9312.1
WA
9314.1
WA
9312.1
WA
9314.1
Cotton
cold 5.0 6.0
Cotton
x
100 1.200
1.400
40°C 5.0 6.0 x
110 1.200
1.400
60°C 5.0 6.0 x
120 1.200
1.400
90°C 5.0 6.0 x
150 1.200
1.400
Synthetic
Kalt 2.5 3.0
Synthetic
x
70 800 800
40°C 2.5 3.0 x
90 800 800
60°C 2.5 3.0 x
110 800 800
Delicate 30°C 1.5 1.5
Sensetive
textiles
x
90 400 400
Quick 30°C 2.5 3.0
All (not very
dirty)
x
35 800 800
Wool
cold 1.5 2.5
Wool
x
55 600 600
40°C 1.5 2.5 x
80 600 600
Wash -- 5.0 6.0 All x
x 40 800 800
