![Bomann WA 9312.1 [15/16] Brand bomann model wa 9312 rated capacity 5kg energy efficiency class a eu ecolabel n a](/img/pdf.png)
Bomann WA 9312.1 [15/16] Brand bomann model wa 9312 rated capacity 5kg energy efficiency class a eu ecolabel n a
![Bomann WA 9312.1 [15/16] Brand bomann model wa 9312 rated capacity 5kg energy efficiency class a eu ecolabel n a](/views2/1080422/page15/bgf.png)
15
05/2012
Overheating
(E7)
NTC resistor is not
switched on.
NTC resistor is defective.
Errors in the wiring harness
or in the electronics.
Set the program selector to
position „Aus“ (Off) and select a
program without heating, so that
the water pumps off.
Too much
foam (E8)
The foam recognition stops
the working of the device at
too much foam.
Excessive detergents are
used. Detergents are used
improperly.
Set the program selector to
position "Aus" (Off) and program
rinse in order to reduce the
foam. Then you can restart the
previsous program.
Contact an authorized technician if the problems are not solved.
■ Care label
Symbol
Illustration
Symbol
Illustration
Hand Wash
No Machine Wash
Washing (including machine wash and hand
wash)
Do not hand-wash
Dry Clean
No Dry Clean
Warmly Dry Clean
No Wring
Bleach
No Bleach
Tumble dry
Do not Tumble Dry
Iron
Do not Iron
Steam Iron
Iron with Cloth
Medium Temperature and max. Temperature
150°C
Dry after Wash
Line Dry
Line Dry in Shade
Are you interested in other Bomann products? Please visit our website:
www.bomann.de
PRODUCT FICHE
Brand: BOMANN
Model: WA 9312.1
Rated capacity: 5kg
Energy efficiency class:A+
EU Ecolabel:N/A
Energy consumption 169 kwh per year, based on 220 standard washing cycles for cotton programmes
at 60°C and 40°C at full and partial load, and the consumption of the low-power modes. Actual energy
consumption will depend on how the appliance is used.
Energy consumption of the Standard cotton 60°C at full load: 0.75kwh
Energy consumption of the Standard cotton 60°C at partial load: 0.79kwh
Energy consumption of the Standard cotton 40°C at partial load: 0.58kwh
Off mode power consumption: 1.0W
Left-on mode power consumption: 2.0W
Water consumption 9.500 litres per year, based on 220 standard washing cycles for cotton pro-
grammes at 60°C and 40°C at full and partial load. Actual water consumption will depend on how the
appliance is used.
