4
05/2012
OVERVIEW OF WASHING MACHINE
■ Delivery scope
User manual (D+GB)
TECHNICAL SPECIFICATIONS
Model
WA 9312
.1
WA 9314
.1
Spin speed
stop -400 -600 -800 -
1.000 -max. 1.200 rpm
stop -400 -600 -800
-1.000 -1.200
-max. 1.400 rpm
Capacity 5 kg 6 kg
Energy Efficiency Class
1)
– Washing Effi-
ciency Class – Spin-Drying Efficiency Class
A+ – A – B A+ – A – B
Estimated annual consumption
2
)
9.500 l / 169 kWh 9.900 l / 196 kWh
Noise level washing / spinning 62 / 77 dBA 62 / 78 dBA
Connection voltage 220-240 V / 50 Hz 220-240 V / 50 Hz
Connection power 2.100 W 2.150 W
Fuse protection 10 A 10 A
Water pressure 0.05 MPa - 1 MPa 0.05 MPa - 1 MPa
Unit sizes (HxWxD) 85,0 x 59,5 x 52,3 cm 85,0 x 59,5 x 53,0 cm
Gross / net -weight ca. 54,0 / 50,0 kg ca. 60,0 / 56,0 kg
Energy test program: Cotton 60°C/40°C, intensive; half load for 4,5 kg / 5 kg / 6 kg / 7 kg machine:
2,25 kg / 2,5 kg / 3,5 kg. Cotton 60°C/40°C + intensive are the standard washing programs to which
the information in the label and the fiche relates and these programs are suitable to clean normally
soiled cotton laundry and that they are the most efficient programs.
1)
Energy efficiency class is defined in point 1 of EU No 1061/2010 Annex VI
2)
The weighted annual energy consumption in kWh/year by 220 cycles rounded up to the nearest
integer and calculated in accordance with point 1(c) of EU No 1061/2010 Annex VII;
and the weighted annual water consumption in litres/year by 220 cycles rounded up to the nearest
integer and calculated in accordance with point 2(a) of EU No 1061/2010 Annex VII.
MANUFACTURER DATA
Product is subject to changes and improvements.
Detergent
drawer
Door
Service
panel
Control p
a
nel
Outlet hose
Power cord
Power plug
Detergent
drawer
Stoppers Inlet hose
