6
01/2012
If required, the door opening can be moved from the right (supplied condition) to the left side.
WARNING
When replacing the door stop, the device must be disconnected from the power supply. Always unplug
the device first.
1. Use a screw-driver to remove the screw covers
(11) at the device top cover. Unscrew the below
screws (10) and remove the device cover (9).
2. Put the blind cap (8) of the device top cover (9) at
the opposite side.
3. Dismount the upper door hinge (5) by unscrewing
the screws (6). Open the door a little, take the
door carefully from the lower door hinge (2).
4. Put the blind cap (7) of the device door at the
opposite side and place the door on a padded
surface to prevent it from scratches.
5. Tilt the device slightly backwards and block it in
this position. Unscrew both feet (3) and (4) and
remove the lower door hinge (2) by unscrewing
the screws (1).
6. Move the hinge (2) to the other side of the device accordingly and fix it with the screws (1).
Screw both feet (3) and (4) on again.
7. Replace the device in the upright position again. Insert the device door on the hinge pin of the low-
er door hinge (2) and fix the door to the property position.
8. Attach the upper door hinge (5) by using the screws (6) to the opposite side accordingly.
9. Put the in point 1 removed device top cover on again, tight the screws (10) and clip the screw cov-
ers (11) on.
Check if the door is arranged vertical as well as horizontal, so that a smooth opening and closing of
the door is ensured.
STARTUP / OPERATION
Prior to first use
ATTENTION
After transport, the device should be left standing for 4 hours in order for the oil to be collected in the
compressor.
Nonobservance could cause damage to the compressor and hence result in failure of the
device. This would void your warranty claim.
• Clean the interior of the device including all accessory parts located inside.
Connect the device to the mains supply
IMPORTANT
• The device must be earthed properly. For this purpose the plug of the mains cable has been fitted
with the intended lead.
• Contact an electrician if the plug does not fit in the wall socket.
• In case you disconnect the device or in case of power failure: Wait for 5 minutes before restarting
the device.
Turning on
Turn on the device by connecting the plug to a wall socket and turning the temperature control, which
is located at the right side of the fridge interior. Please also refer to chapter “Settings“.
Settings
Setting 0 – OFF indicates the device is turned off.
Turn the temperature control clockwise, starting from this setting; the device will turn on automatically.
The Settings 1 MIN – 7 MAX regulate the inside temperature. When opening the door, the interior
lamp will turn on.
Setting 0 (or OFF) = Off
