16
English
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specifi ed.
7. If the battery charging fails to complete even when a
specifi ed recharging time has elapsed, immediately
stop further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fi re immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove
it from the equipment or battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you fi nd rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the fi rst time, do not use and return it to your
supplier or vendor.
WARNING
If an electrically conductive foreign object enters the
terminals of the lithium ion battery, a short-circuit may
occur resulting in the risk of fi re. Please observe the
following matters when storing the battery.
◯ Do not place electrically conductive cuttings,
nails, steel wire, copper wire or other wire in the
storage case.
◯ Either install the battery in the power tool or store
by
securely pressing into the battery cover until
the ventilation holes are concealed to prevent
short-circuits (See Fig. 1).
SPECIFICATIONS
POWER TOOL
Model CG14DSDL CG18DSDL
Pole type Straight type
Cutting capacity diameter 310 mm
Rotation direction Counterclockwise as seen from above
No-load speed 5000 min
-1
Operating time on one charge *
1
(When supplied rechargeable battery is fully charged)
17 – 18 min*
2
24 – 26 min*
2
Battery
BSL1430: Li-ion 14.4 V
(3.0 Ah 8 cells)
BSL1830: Li-ion 18 V
(3.0 Ah 10 cells)
Weight (with nylon head, rechargeble battery and
cover)
4.1 kg 4.3 kg
*1 The data in the above table is provided only as an example. Since type of grass, ambient temperature, rechargeable
battery characteristics, work methods, etc. can vary widely the above should only be used as a rough guideline.
*2 Conditions: Outer diameter of nylon head 310 mm, switch set to full speed. (switch left ON all the time)
CHARGER
Model UC18YGSL UC18YRSL
Charging voltage 14.4 V – 18 V
Battery BSL1430, BSL1830
Weight 0.4 kg 0.6 kg
STANDARD ACCESSORIES
CG14DSDL
(LSC)
1 Battery (BSL1430) ................................1
2 Charger (UC18YGSL) ...........................1
3 Nylon head ............................................1
4 Cover ....................................................1
5 Hex. bar wrench 4 mm ..........................1
6 17×19 Combi box wrench .....................1
7 Protective glass ....................................1
CG14DSDL
(2LSC)
1 Battery (BSL1430) ................................2
2 Charger (UC18YGSL) ...........................1
3 Nylon head ............................................1
4 Cover ....................................................1
5 Hex. bar wrench 4 mm ..........................1
6 17×19 Combi box wrench .....................1
7 Protective glass ....................................1
8 Battery cover ........................................1
CG18DSDL
(NN)
1 Nylon head ............................................1
2 Cover ....................................................1
3 Hex. bar wrench 4 mm ..........................1
4 17×19 Combi box wrench .....................1
5 Protective glass ....................................1
