CAUTION
If the battery is charged while it is heated because it has
been left for a long time in a location subject to direct
sunlight or because the battery has just been used,
the pilot lamp of the charger lights for 1 second, does
not light for 0.5 seconds (o for 0.5 seconds). In such a
case, rst let the battery cool, then start charging.
When the pilot lamp ickers (at 0.2-second intervals),
check for and take out any foreign objects in the
charger’s battery connector. If there are no foreign
objects, it is probable that the battery or charger is
malfunctioning. Take it to your authorized Service
Center.
Since the built-in micro computer takes about 3
seconds to con rm that the battery being charged
with UC18YGSL is taken out, wait for a minimum of 3
seconds before reinserting it to continue charging. If
the battery is reinserted within 3 seconds, the battery
may not be properly charged.
ABOUT POWER LAMP
The power lamp indicates various statuses for the tool.
(Fig. 7)
Table 4 shows the various statuses indicated by the power
lamp.
Table 4
State of lamp Status of Tool
O Power OFF
Red Power ON
Blinking red
The over-heat protection circuit
of the tool is operating.
The lever is being pressed while
the overload protection circuit of
the tool is operating.
Quickly blinking red The tool is operating abnormally.
ABOUT REMAINING BATTERY INDICATOR
The remaining battery lamp blinks when the remaining
battery power is low.
Please charge the tool as soon as possible. The Table 5
shows the state of remaining battery indicator lamp and the
battery remaining power.
Table 5
State of lamp Battery Remaining Power
The battery remaining power is
enough.
The battery remaining power is nearly
empty.
Re-charge the battery soonest
possible.
As the remaining battery indicator shows somewhat
di erently depending on ambient temperature and battery
characteristics, read it as a reference.
NOTE
Do not give a strong shock to the switch panel or break
it. It may lead to a trouble.
PRIOR TO OPERATION
CAUTION
Pull out battery before doing any assembly.
1. Installing the loop handle (Fig. 8)
(1) Remove the M6 × 43 bolts (2 pcs.).
(2) Install the loop handle on the main pipe so that it leans
against the housing.
(3) Place the handle xture at the lower end of the main
pipe and secure it rmly using M6 × 43 bolts (2 pcs.)
and M6 nuts (2 pcs.).
NOTE
Secure the loop handle in a location that provides a
good grip.
CAUTION
Install the loop handle properly and securely as
instructed in the handling instructions.
If not attached properly or securely, it may come o and
cause injury.
2. Installing cover (See Fig. 9 and 10)
WARNING
Be sure to install the cover in its designated location.
Failure to heed this warning may result in injury from
ying stones.
NOTE
Use the supplied hex. bar wrench 4 mm for installation.
(1) Use the supplied D5 tapping screw to install the knife in
the cover. (Fig. 9)
(2) Align the two holes in the cover bracket and the cover
and insert two M6 × 25 hex. socket button bolts. (The
cover bracket is installed in the motor case.)
(3) Place the cover holder on the underside of the cover and
use the supplied hex. bar wrench 4 mm to alternately
tighten the two M6 × 25 hex. socket button bolts until
they are properly tightened.
CAUTION
Take care to avoid cutting yourself on the knife inside
the cover.
Install the cover and knife properly and securely as
instructed in the handling instructions.
If not attached properly or securely, they may come o
and cause injury.
NYLON HEAD
Installation of semi-auto nylon head
1. Function
Automatically feeds more nylon cutting line when it is
tapped.
Speci cations
Code
No.
Type of
attaching
screw
Direction of rotation
Size of
attaching
screw
333903
Female
screw
Counterclockwise
M10×
P1.25-LH
Applicable nylon cord
Cord diameter: Φ1.4 mm
Length: 6 m
CAUTION
The case must be securely attached to the cover.
Check the cover, case and other components for cracks
or other damage.
Check the case and button for wear.
If the wear limit mark on the case is no longer visible or
there is a hole in the bottom of the button, change the
new parts immediately. (Fig. 14)
