Haier ADH250H1ERG [15/28] Accessories
![Haier ADH250H1ERG [15/28] Accessories](/views2/1812488/page15/bgf.png)
15
ADH200H1ERG/ADH250H1ERG
Accessories
No. name Quantity Descriptions Shape
1 Signal line 1
Connection between the
wired remote control and
electric control board
2 Remote controller 1
For Air conditioner
operation
3
1/2 Brass nut (liquid
side)
1
4
3/4 Brass nut (gas
side)
1
5
Coupler heat
insulation(gas side)
1
For indoor side pipe
joint(gas side)
6
Coupler heat
insulation(liquid side)
1
For indoor side pipe
joint(liquid side)
7 Instructions 1 Air conditioner operation
8 Cable tie(Large) 4 For fixing the heat insulation
9 Cable tie(Small) 4
For fixing the remote
controller cable and
connecting cable
For tightenning the
Connecting pipe
