Haier ADH250H1ERG [8/28] Parts and functions
![Haier ADH250H1ERG [8/28] Parts and functions](/views2/1812488/page8/bg8.png)
ADH071M1ERG
ADH105M1ERG ADH125M1ERG ADH140M1ERG
ADH090M1ERG
ADH105H1ERG ADH125H1ERG ADH140H1ERG ADH160H1ERG
ADH071M3ERG
8
Parts and Functions
ADH250H1ERG ADH200H1ERG
The pump
drain opening
Electrical components Case
Drain pan
Evaporator
Air outlet frame
Air outlet frame
Drain pan
Evaporator
The pump
drain opening
Electrical components Case
Air outlet frame
Fan
Drain pan
The drain opening
Electrical components Case
