English
5
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position. If
the plug is connected to a power receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, which could cause a
serious accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Confirm the direction of bit rotation (Fig. 1)
The bit rotates clockwise (viewed from the rear
side) when the reversing switch lever is set to the
“R” side position. When the lever is set to the “L”
side position, the bit rotates counterclockwise and
can be used to loosen and remove screws.
5. Adjusting the tightening depth (Fig. 2)
The tightening depth can be adjusted by turning
locator right and left click feeling.
(1) For hex-head screws:
Mount a hex-head screw on the hex-socket and set
the distance between the sub-stopper end and the
screw head neck to 1–1.5 mm, as shown in Fig. 3.
(2) For drywall screws:
Mount a drywall screw on the bit, and set the
distance between the sub-stopper end and the screw
head to 1.5–2 mm, as shown in Fig. 4.
(3) For cross-recessed self-drilling screws:
Mount a self-drilling screw on the bit, and set the
distance between the sub-stopper end and the screw
head bottom to 1–1.5 mm, as shown in Fig. 5.
6. Mounting the bit
For details, refer to the item “Mounting and
dismounting the bit”.
MOUNTING AND DISMOUNTING THE HEX-
SOCKET OR THE BIT
1. Dismounting the hex-socket (Fig. 6)
(1) While rotating the Sub-Stopper pull it out from the
locator.
(2) Remove the hex-socket, hold it with the opposite
side of bit by hand or vise and pull out the bit with
pliers.
2. Dismounting the bit (Fig. 7)
Remove sub-stopper (G) as the same manner of
hex-head socket and remove the bit holder, then
pull out the bit with pliers.
3. Dismounting the bit (Fig. 8)
Remove the sub-stopper (F) as the same manner
of hex-head socket and remove the bit holder, then
pull out the bit with pliers.
4. Mounting the hex-socket or the bit
Install the bit in the reverse order to removal.
HOW TO USE THE SCREW DRIVER
1. Switch operation and rotational speed adjustment
Bit rotational speed can be adjusted between 0 –
6000 min
-1
(W6VM) or 0 – 4500 min
-1
(W6V4) or
0 – 3000 min
-1
(W6VA4) or 0 – 2600 min
-1
(W6VB3)
or 0 – 1700 min
-1
(W8VB2) varying the degree by
which the trigger switch is pulled. Rotational speed
increases as the trigger switch is pulled, and reaches
a maximum speed of 6000 min
-1
(W6VM) or 4500
min
-1
(W6V4) or 3000 min
-1
(W6VA4) or 2600
min
-1
(W6VB3) or 1700 min
-1
(W8VB2) when the
trigger switch is pulled fully.
To facilitate continuous operation, pull the trigger
switch and depress the switch stopper. The switch
will then remain ON even when the finger is released.
By pulling the trigger switch again, the switch
stopper disengages and the switch is turned OFF
when the trigger switch is released.
2. Screw Driver operation
When the switch is turned ON, the motor starts to
run but the hex-socket (or the bit) does not rotate.
Attach the hex-socket to the screw head groove,
and push the Screw Driver against the screw. The
hex-socket then rotates and tightens the screw.
CAUTION
Ensure that the Screw Driver is held truly
perpendicular to the head of the screw.
If held at an angle, the driving force will not be
fully transferred to the screw, and the screw head
and/or hex-socket will be damaged. Hex-socket
rotation stops when pushing force is released.
3. Direction of hex-socket rotation
The hex-socket rotates clockwise (viewed from the
rear side) when the reversing switch lever is set
to the “R” side position. When the lever is set to
the “L” side position, the hex-socket rotates counter-
clockwise, and can be used to loosen and remove
screws.
CAUTION
Never change the direction of hex-socket (or bit
holder) rotation while the motor is running. To do
so would seriously damage the motor. Turn the
power switch OFF before changing the direction
of hex-socket (or bit holder) rotation.
MAINTENANCE AND INSPECTION
1. Inspecting the hex-socket (or bit)
Since continued use of a worn hex-socket (bit) will
damage screw heads, replace the hexsocket (bit)
with a new one as soon as excessive wear is
noticed.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure
that they are properly tightened. Should any of the
screws be loose, retighten them immediately. Failure
to do so could result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very ”heart” of the
power tool. Exercise due care to ensure the winding
does not become damaged and/or wet with oil or
water.
