AU422FIBIA
No. Specialized Number Name Quantity
1 001A0100122 Front guard assy 2
2 001A0100493 Service panel assy 1
3 001A1301640 Front panel 1
4 001A5402022 Axial fan 2
5 001A3000201 Outdoor motor 2
6 001A0100826 Motor braket assy 1
7 001A17421215 Pole foam 1
8 0010150076 Pole 1
9 0010750925 Condenser assy 1
10 001A17341206 Rubber pad. 1
11 001A3400138 Pressure switch 1
12 001A2500094 Electromagnetic valve winding A 1
13 001A5736055 Ambient temp.sensor nip 1
14 001A0100827 Top cover assy 1
15 001A0100767 Back guard assy 1
16 001A0100494 Right panel assy 1
17 001A1436160 Handle 1
18 001A1301465 Fix plate 1
19 001A3800105 Sensor of B system 1
20 001A2500087 Winding B of PMV 1
21 001A2500095 Electromagnetic valve winding B 1
22 0010750904 Compressor 2
23 0010750966 2-way stop valve 1
0010750968 2-way stop valve 1
24 0010750967 3-way stop valve 1
0010750969 3-way stop valve 1
25 001A1301685 Pole 3
26 001A0100497 Bottom assy 1
27 001A13011200 Braket for compressor 1
28 001A3800097 Reactor 1
29 001A1301470 Reactor cover 1
30 0010850202 Partition plate 1
31 001A0600400 Cover of electrical box 1
32 001A1301464 Supporting plate 1
