Haier AE182FCAKA [143/174] Parts list
![Haier AS062FMAHA [143/174] Parts list](/views2/1821666/page143/bg8f.png)
No.
Spare parts
number
Spare parts description in
English Qty. Model
Failur
e rate
the
proportion of
the spare-
part stock Remark
1 0010150073 Electrical box 1 AU482FIAIA 0.00% 0.000% ×
2 0010450036 PCB 1 1 AU482FIAIA 0.02% 0.024% *
3 0010450184 power supply Terminal board 1 AU482FIAIA 0.00% 0.000% ×
4 / / / AU482FIAIA
5 001A5745116 Terminal board 1 AU482FIAIA 0.00% 0.000% ×
6 0010450037 PCB 2 1 AU482FIAIA 0.02% 0.024% *
7 0010450187 rectifier 2 AU482FIAIA 0.00% 0.000% ×
0010450188 rectifier 1 AU482FIAIA 0.00% 0.000% ×
8 0010450201 power module 2 AU482FIAIA 0.00% 0.000% ×
9 0010450200 dispel heat patch 1 AU482FIAIA 0.00% 0.000% ×
10 / / / AU482FIAIA
11 0010450189 electrolyse capacitance 1 1 AU482FIAIA 0.04% 0.048% *
12 0010450190 electrolyse capacitance 2 2 AU482FIAIA 0.04% 0.048% *
13 001A3600018 Capacitor for fan motor 2 AU482FIAIA 0.04% 0.048% *
14 0010150075 Electrical box(level) 1 AU482FIAIA 0.00% 0.000% ×
Parts list
No.
Spare parts
number Spare parts description in English Qty. Model
Failure
rate
proportion
of the
spare-part
stock Remark
1 0010150073 Electrical box 1 AU48NFIAIA 0.00% 0.000% ×
2 0010450520 PCB 1 1 AU48NFIAIA 0.02% 0.024% *
3 0010450184 Power supply Terminal board 1 AU48NFIAIA 0.00% 0.000% ×
5 001A5745116 Terminal board 1 AU48NFIAIA 0.00% 0.000% ×
6 0010450506 PCB 2 1 AU48NFIAIA 0.02% 0.024% *
7 0010450676 Rectifier 1 AU48NFIAIA 0.00% 0.000% ×
8 0010450201 Power module 2 AU48NFIAIA 0.00% 0.000% ×
9 0010450200 Dispel heat patch 1 AU48NFIAIA 0.00% 0.000% ×
11 0010450642 Electrolyse capacitance 2 AU48NFIAIA 0.04% 0.048% *
13 001A3600018 Capacitor for fan motor 2 AU48NFIAIA 0.04% 0.048% *
14 0010150075 Electrical box(level) 1 AU48NFIAIA 0.00% 0.000% ×
Parts list
