Haier AE182FCAKA [63/174] Electrical control functions
![Haier AE122FCAKA [63/174] Electrical control functions](/views2/1821666/page63/bg3f.png)
6.1.1 In order to control all indoor units of H-MRV systems, the indoor units number should be set after
installation work. We have two ways to set indoor unit number according to indoor unit type. Normally
the infrared remote control types use special remote controller to do indoor unit number setting, the wired
types use dialing switch (on indoor unit PCB) to do indoor unit number setting. The details is as follows :
6 ELECTRICAL CONTROL FUNCTIONS
No. Model Type Refrigerant Remote controller Address setting Remark
1 AU422FIAHA
Outdoor
R22 / /
with lock switch
2 AU422FIAIA
Outdoor
R22 / /
with lock switch
3 AU422FIBIA
Outdoor
R407C / /
with lock switch
4 AU242FHAHA
Outdoor
R22 / /
without lock switch
5 AU242FHBHA
Outdoor
R407C / /
without lock switch
6 AB092FCBHA
Indoor
R407C Wireless
Special remote controller
/
7 AB142FCBHA
Indoor
R407C Wireless
Special remote controller
/
8 AB182FCAHA
Indoor
R22 Wireless
Special remote controller
/
9 AB182FCBHA
Indoor
R407C Wireless
Special remote controller
/
10 AC142FCBHA
Indoor
R407C Wireless
Special remote controller
/
11 AC182FCAHA
Indoor
R22 Wireless
Special remote controller
/
12 AC182FCBHA
Indoor
R407C Wireless
Special remote controller
/
13 AD142FCBHA
Indoor
R407C Wired Dialing switch /
14 AD182FCBHA
Indoor
R407C Wired Dialing switch /
15 AE092FCAHA
Indoor
R22 Wired Dialing switch /
16 AE092FCBHA
Indoor
R407C Wired Dialing switch /
17 AE112FCBIA
Indoor
R407C Wired Dialing switch /
18 AE182FCAHA
Indoor
R22 Wired Dialing switch /
19 AE182FCBHA
Indoor
R407C Wired Dialing switch /
20 AE182FCBIA
Indoor
R407C Wired Dialing switch /
21 AF092FCBHA
Indoor
R407C Wireless
Special remote controller
/
22 AF122FCBHA
Indoor
R407C Wireless
Special remote controller
/
23 AP182FAAHA
Indoor
R22 Wireless
Special remote controller
/
24 AP182FABHA
Indoor
R407C Wireless
Special remote controller
/
25 AS092FMAHA
Indoor
R22 Wireless
Special remote controller
/
26 AS092FMBHA
Indoor
R407C Wireless
Special remote controller
/
27 AS182FTAHA
Indoor
R22 Wireless
Special remote controller
/
28 AS182FTBHA
Indoor
R407C Wireless
Special remote controller
/
6.1 Indoor unit NO. Setting method
